Philips 21PT5027/69 - Page 3

Technical Specifications, Connections, and Chassis Overview
EN 3TC8.1A CA 1.
1.3 Chassis Overview
Figure 1-2 PWB/CBA locations (depending on model)
MONO CARRIER
H_17130_039.eps
070507
SIDE AV PANEL +
HEADPHONE
B
D
CRT PANEL
A
