2. TV Monitor Description
The TV monitor will contain a scaler board, a power board, an IR board and a key board. The scaler board houses
the flat panel control logic, brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the scaler board chips
each voltage.
TV Monitor Block Diagram
AC-IN
100V-240V
Power Board
(Include: Adapter, Inverter)
Flat Panel and
CCFL backlight
Scaler Board
CVI
USB
HDMI
SPDIF
RS232
VIDEO
TUNER
SCART
PC VGA/
A
UDIO
CCFL Drive.
AV Signal, DDC
Key Board
HOST Computer
IR Board
