5.3
Reception
• Aerial input : 75 ohm coaxial (IEC75)
• Tuner bands : UHF, VHF
• DVB : DVB-T2, DVB-C (cable) QAM, DVB-T
• Analogue video playback : SECAM, PAL, NTSC
• Digital video playback : MPEG2 SD/HD (ISO/IEC
13818-2), MPEG4 SD/HD (ISO/IEC 14496-10), HEVC*
• Digital audio playback (ISO/IEC 13818-3)
• Input frequency range : 45 to 866 MHz
• Input level range : 60 to 72 dBuv
5.4
Display Type
Diagonal screen size
• 60 cm / 24 inch
• 80 cm / 32 inch
• 108 cm / 43 inch
• 126 cm / 50 inch
5.5
Display Input Resolution
Video formats
Resolution — Refresh rate
• 480i - 60 Hz
• 480p - 60 Hz
• 576i - 50 Hz
• 576p - 50 Hz
• 720p - 50 Hz, 60 Hz
• 1080i - 50 Hz, 60 Hz
• 1080p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz
Computer formats
Resolutions (amongst others)
• 640 x 480 - 60 Hz
• 800 x 600 - 60 Hz
• 1024 x 768 - 60 Hz
• 1280 x 800 - 60 Hz
• 1280 x 960 - 60 Hz
• 1360 x 768 - 60 Hz
• 1280 x 1024 - 60 Hz
• 1440 x 900 - 60 Hz
• 1920 x 1080 - 60 Hz
5.6
Connectivity
TV Side
• Common Interface slot: CI+/CAM
• USB - USB 2.0
• Headphones - Stereo mini-jack 3.5mm
TV Back
• HDMI 1 in - ARC - FHD
• HDMI 2 in - FHD
• VGA
• Antenna (75 ohm)
• SCART (RGB/CVBS)
• Audio in DVI/VGA
• Audio out - Optical Toslink
5.7
Dimensions and Weights
24HFL3014
• without TV stand:
Width 559.65 mm - Height 335.78 mm - Depth 54.1
mm - Weight ± 3.15 kg
• with TV stand:
Width 559.65 mm - Height 335.78 mm -
Depth 124.1 mm - Weight ± 3.2 kg
32HFL3014
• without TV stand:
Width 731.8 mm - Height 435.31 mm - Depth 77.3
mm - Weight ± 4.62 kg
• with TV stand:
Width 731.8 mm - Height 455.52 mm -
Depth 166.23 mm - Weight ± 4.68 kg
43HFL3014
• without TV stand:
Width 969.64 mm - Height 565.58 mm -
Depth 80.5 mm - Weight ± 7.2 kg
• with TV stand:
Width 969.65 mm - Height 581.16 mm -
Depth 218.06 mm - Weight ± 7.3 kg
50HFL3014
• without TV stand:
Width 1127.63 mm - Height 655.3 mm - Depth 85.9
mm - Weight ± 11.15 kg
• with TV stand:
Width 1127.63 mm - Height 676.3 mm - Depth 241.3
mm - Weight ± 11.4 kg
10
