Philips 24PHS5507/12 - 715 G8791 IR Board

9.6 J 715G8791 IR Board(For 24” 5507/5537 Series)
9-6-1 IR BOARD
U001
IRM-H936M3/TR2
GND
1
GND
2
OUT
3
VCC
4
VCC
CN001
CONN
1
2
3
4
5
6
7
Q001
BC847C
R002
1K 1/16W 5%
R001
4K7 1/16W 5%
VCC
LED001
GPTS06033RC3-PB
12
ZD001
VPORT0603100KV05
1 2
----><----|
R004
100R 1/16W 5%
C002
NC/1N 50V
VCC
R003
NC/10K 1/16W 5%
Close to U001
C003
100N 16V
LED
NC
VCC
GND
IR
C001
10UF 6.3V
