8
2. Setting up the monitor
2.3 Remove the Base Assembly for
VESA Mounting
Before you start disassembling the monitor
base, please follow the instructions below to
avoid any possible damage or injury.
1. Extend the monitor base to its maximum
height.
2. Place the monitor face down on a smooth
surface. Pay attention not to scratch or
damage the screen. Then lift the monitor
stand.
3. While keeping the release button pressed,
tilt the base and slide it out.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface.
100mm
100mm
