Philips 288P6 - Page 13

11
2. Setting up the monitor
• PIP / PBP Input: There are four different
video input to choose as the sub
display source: [DVI], [MHL-HDMI], and
[DisplayPort].
• PIP Size: When PIP is activated, there are
three sub-window sizes to choose: [Small],
[Middle], [Large].
B
A (main)
Small
Middle
Large
• PIP Position: When PIP is activated, there
are four sub-window positions to choose.
Top-Right Bottom-Right
B
A (main)
A (main)
B
Top-Left Bottom-Left
• Swap: The main picture source and the
sub picture source swapped on the
display.
Swap A and B source in [PIP] mode:
B
A (main)
↔
B (main)
A
Swap A and B source in [PBP] mode:
B A(main)
↔
A B(main)
• Off: Stop MultiView function.
A (main)
Note
• When you do the SWAP function, the video
and its audio source will swap at the same
time. (Refer to page 7 “Independent
audio playback, regardless of video input”
formoredetail.)
B
A (main)
B
A
(main)
