Revision List
EN 2 TPM14.1HE LA1.
2014-May-16
back to
div. table
1. Revision List
Manual xxxx xxx xxxx.0
• First release
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections (for 3009D series)
2.4 Connections ( for 5009D series)
2.5 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 9 10 11
Connection Overview
Mechanics
Block Diagram
Schematics
Styling Wire Dressing Rear Cover Removal SSB Removal Power Supply SSB J (IR/LED panel) E (Keyboard/Leading Edge) HC (BOLT-ON board)
24HFL3009D/12 2-1 4-1 4-10 4-11 9.1 10.3 10.7 10.8 - 10.11 11.1
28HFL3009D/12 2-1 4-2 4-10 4-11 9.1 10.2 10.7 10.8 - 10.11 11.2
28HFL5009D/12 2-7 4-3 4-12 4-13 9.1 10.2 10.7 10.8 - 10.11 11.3
32HFL3009D/12 2-1 4-4 4-10 4-11 9.1 10.2 10.7 10.9 - 10.11 11.4
32HFL5009D/12 2-7 4-5 4-14 4-15 9.1 10.1 10.7 - 10.10 10.11 11.5
40HFL3009D/12 2-1 4-6 4-16 4-17 9.1 10.5 10.7 10.9 - 10.11 11.6
40HFL5009D/12 2-7 4-7 4-18 4-19 9.1 10.4 10.7 - 10.10 10.11 11.7
48HFL5009D/12 2-7 4-8 4-14 4-15 9.1 10.4 10.7 - 10.10 10.11 11.8
55HFL5009D/12 2-7 4-9 4-18 4-19 9.1 10.6 10.7 - 10.10 10.11 11.9
