24TPT1.1HA LA 6.
Block Diagrams, Test Point Overviews, and Waveforms
Block Diagram Video
TUNER
YPbPr 1
CVBS/S -V ideo
S/PDIF Output
Audio Output CVBS
Output
YPbPr 2
PX66
Scaler /ADC
Video
processing
MCU
Key pad
IR / Power switch
SRAM
Flash memory
DDR memory
Power supply
(regulator/
Switch)
Manage unit
to each block
Panel interface
1920*1080
(1366*768)
Control interface
PC_ D-sub
HDMI_1
Side CVBS/S -video
EEPROM
EDID/
RS232
EDID
Audio DAC/SPDIF
HDMI_2
HDMI
switch
RS232 service &ComPair port
iTV
CVBS
Sync slicer
CVBS &
H/V
sync
H_17010_052.eps
190907
