Spare Parts List
EN 73TPT1.1HA LA 10.
R903 9965 000 43878 240kΩ 5% 1/4W
R910 9965 000 43880 330kΩ 1% 1/4W
R911 9965 000 43880 330kΩ 1% 1/4W
R912 9965 000 43880 330kΩ 1% 1/4W
R913 9965 000 43400 620Ω 1% 1/8W
R914 9965 000 43398 5.6kΩ 1% 1/8W
R917 9965 000 43390 22kΩ 5% 1/8W
R918 9965 000 42284 0Ω 1/10W
R920 9965 000 43902 0.15Ω 1% 1W
R921 9965 000 43877 6.2kΩ 5% 1/8W
R922 9965 000 43380 1kΩ 1/10W
R924 9965 000 43395 33kΩ 5% 1/8W
R925 9965 000 43874 47Ω 5% 1/8W
R925 9965 000 44294 47Ω 5% 1/8W
R926 9965 000 36987 10Ω 5% 1/4W
R926 9965 000 38141 10Ω 5% 1/6W
R927 9965 000 43881 820kΩ 5% 1/4W
R928 9965 000 43881 820kΩ 5% 1/4W
R929 9965 000 43881 820kΩ 5% 1/4W
R930 9965 000 43868 16kΩ 5% 1/8W
R931 9965 000 42284 0Ω 1/10W
R932 9965 000 43898 7.5kΩ 5% 1/4W
R932 9965 000 43901 7.5kΩ 5% 1/6W
R936 9965 000 43381 10kΩ 1/10W
R937 9965 000 43393 330Ω 5% 1/8W
R938 9965 000 43869 18Ω 5% 1/8W
R939 9965 000 43381 10kΩ 1/10W
R940 9965 000 43896 1kΩ 5% 1/4W
R940 9965 000 43899 1kΩ 5% 1/6W
R942 9965 000 43869 18Ω 5% 1/8W
R950 9965 000 43903 0.33Ω 5% 1W
R952 9965 000 43896 1kΩ 5% 1/4W
R952 9965 000 43899 1kΩ 5% 1/6W
R953 9965 000 43867 150Ω 5% 1/8W
R953 9965 000 44295 150Ω 5% 1/8W
R954 9965 000 36987 10Ω 5% 1/4W
R954 9965 000 38141 10Ω 5% 1/6W
R955 9965 000 43390 22kΩ 5% 1/8W
R957 9965 000 43897 130kΩ 5% 1/4W
R957 9965 000 43900 130kΩ 5% 1/6W
R965 9965 000 43379 100Ω 5% 1/8W
R966 9965 000 43379 100Ω 5% 1/8W
R967 9965 000 43380 1kΩ 1/10W
R968 9965 000 39749 100kΩ 0805
R970 9965 000 43896 1kΩ 5% 1/4W
R970 9965 000 43899 1kΩ 5% 1/6W
R971 9965 000 43870 19.6kΩ 1% 1/8W
R972 9965 000 43389 2.2kΩ 1% 1/8W
R972 9965 000 44296 2.2kΩ 1% 1/8W
R974 9965 000 43381 10kΩ 1/10W
R974 9965 000 44297 10kΩ 5% 1/8W
R979 9965 000 43875 4.7kΩ 1% 1/8W
R990 9965 000 43872 2.2kΩ 5% 1/8W
R991 9965 000 43876 4.7kΩ 5% 1/8W
R992 9965 000 42284 0Ω 1/10W
R994 9965 000 39749 100kΩ 0805
R995 9965 000 43873 39kΩ 1% 1/8W
R996 9965 000 43875 4.7kΩ 1% 1/8W
R998 9965 100 04669 20.5kΩ 1% 1/8W
VAR901 9965 100 02714 TVR14511KFC4FY
b
L901 9965 000 43847 Line Filter 6mH 1.8A
L901 9965 000 43848 Line Filter 6mH 2.0A
L903 9965 000 43843 Choke coil 430μH 0.19Ω
L903 9965 100 04967 Choke coil 430μH 0.19Ω
L910 9965 000 43849 Line Filter 11mH 3.5A
L910 9965 000 43850 Line Filter 11mH 3.5A
L966 9965 000 43361 15μH 10%
L966 9965 000 43845 Choke coil 15μH 260MΩ
L966 9965 000 43846 Choke coil 15μH 260MΩ
L966 9965 100 02517 Choke coil 15μH 260MΩ
L970 9965 000 42610 Choke Coil
L970 9965 000 43841 Choke 35μH 10% 82MΩ
L983 9965 000 43360 10μH 10%
L983 9965 000 43842 Choke coil 10μH 17MΩ
L983 9965 000 43844 Choke coil 10μH 14.6MΩ
L983 9965 100 02516 Choke coil 10μH 14.6MΩ
T901 9965 000 43851 XFMR PPH6004AL
T901 9965 100 02519 HJC-S6197
d
D901 9965 000 43857 STTH5L06FP
D926 9965 000 36035 LL4148WP
D926 9965 000 43891 MLL4148 SMD
D926 9965 100 03321 LL4148-GSO8
D934 9965 000 40067 RGP10-DO-204AL
D934 9965 000 43435 BYT42D
D934 9965 000 43436 RGP10D
D935 9965 000 40067 RGP10-DO-204AL
D935 9965 000 43435 BYT42D
D935 9965 000 43436 RGP10D
D950 9965 000 40067 RGP10-DO-204AL
D950 9965 000 43435 BYT42D
D950 9965 000 43436 RGP10D
D951 9965 000 40067 RGP10-DO-204AL
D951 9965 000 43435 BYT42D
D951 9965 000 43436 RGP10D
D953 9965 000 36035 LL4148WP
D953 9965 000 43891 MLL4148 SMD
D953 9965 100 03321 LL4148-GSO8
D955 9965 000 36035 LL4148WP
D955 9965 000 43891 MLL4148 SMD
D955 9965 100 03321 LL4148-GSO8
D957 9965 000 43426 Trans Suppr 120V 5W
D957 9965 000 43434 P6KE120A DO-15
D958 9965 000 43437 UF1007 1A 1000V
D958 9965 000 43438 STTH110
D959 9965 000 43426 Trans Suppr 120V 5W
D959 9965 000 43434 P6KE120A DO-15
D960 9965 000 36034 SP10150
D960 9965 000 43855 MBRF10150CT
D960 9965 000 43856 MBRF10150CT
D961 9965 000 36034 SP10150
D961 9965 000 43855 MBRF10150CT
D961 9965 000 43856 MBRF10150CT
D970 9965 000 43904 SB240
D970 9965 000 43905 SB240-13-F DO-41
D970 9965 100 02828 SB240
ce
IC920 9965 000 43861 UCC28051D
IC950 9965 000 43860 FA5541N
IC970 9965 000 43859 LA5779L-HK
IC990 9965 000 36055 PC123Y22FZOF
IC990 9965 000 40055 PC123 Y82FZ0F
IC990 9965 000 40056 TCET1103G
IC991 9965 000 36055 PC123Y22FZOF
IC991 9965 000 40055 PC123 Y82FZ0F
IC991 9965 000 40056 TCET1103G
IC995 9965 000 43819 TL431CZ-AP
IC995 9965 100 02780 AZ431AZ-AE1
Q901 9965 000 43862 Mosfet_20A/600V
Q901 9965 000 43863 Mosfet_20A/600V
Q901 9965 000 43865 STP25NM60N 20A/600V
Q902 9965 000 43864 Mosfet STP10NK80ZFP
Q936 9965 000 35967 KEC 2N3906S-RTK/PS
Q936 9965 100 02478 PMBS3906
Q988 9965 000 36033 RK7002
Q988 9965 000 42650 2N7002 SOT-23
Q988 9965 000 42651 2N7002 SOT-23
Q992 9965 000 36033 RK7002
Q992 9965 000 42650 2N7002 SOT-23
Q992 9965 000 42651 2N7002 SOT-23
Q993 9965 000 35966 PMBS3904
Q993 9965 000 36961 KEC 2N3904S-RTK/PS
Q993 9965 000 40045 MMBT3904
BD901 9965 000 43858 Bridge 6A/600V
BD901 9965 000 44288 GBU606
BD901 9965 100 03552 GBU605
NR901 9965 000 43820 NTC SCK101R55LSY
TV & Scaler Board [S-A]
Various
1256 9965 100 06763 EEPROM ASSY-U4101
1256 9965 100 08391 EEPROM ASSY
1257 9965 100 06764 FLASH ASSY_U4502
1257 9965 100 08392 FLASH ASSY
FB1101 9965 000 45218 Bead 10 Ohm/500mA
FB1102 9965 000 45218 Bead 10 Ohm/500mA
FB1103 9965 000 45218 Bead 10 Ohm/500mA
FB1104 9965 000 43997 Bead 600Ω/500mA
FB1104 9965 100 02513 Bead 600Ω/200mA
FB1105 9965 000 43997 Bead 600Ω/500mA
FB1105 9965 100 02513 Bead 600Ω/200mA
FB1106 9965 000 45219 Bead 600 Ohm/300mA
FB1107 9965 000 45219 Bead 600 Ohm/300mA
FB1201 9965 100 02512 Bead 100 Ohm 3A
FB1202 9965 000 45218 Bead 10 Ohm/500mA
FB1203 9965 000 45218 Bead 10 Ohm/500mA
FB1204 9965 000 45219 Bead 600 Ohm/300mA
FB1205 9965 000 45218 Bead 10 Ohm/500mA
FB1206 9965 000 45219 Bead 600 Ohm/300mA
FB1207 9965 000 45218 Bead 10 Ohm/500mA
FB1208 9965 000 45218 Bead 10 Ohm/500mA
FB1209 9965 000 45218 Bead 10 Ohm/500mA
FB1211 9965 100 03317 Bead 120 Ohm/500mA
FB1213 9965 000 45219 Bead 600 Ohm/300mA
FB1214 9965 100 03317 Bead 120 Ohm/500mA
FB1216 9965 000 45219 Bead 600 Ohm/300mA
FB1217 9965 100 03317 Bead 120 Ohm/500mA
FB1219 9965 000 45219 Bead 600 Ohm/300mA
FB1220 9965 100 03317 Bead 120 Ohm/500mA
FB1221 9965 100 03317 Bead 120 Ohm/500mA
FB1222 9965 000 45219 Bead 600 Ohm/300mA
FB1223 9965 100 03317 Bead 120 Ohm/500mA
FB1224 9965 000 45219 Bead 600 Ohm/300mA
FB1225 9965 000 45219 Bead 600 Ohm/300mA
FB1226 9965 000 45219 Bead 600 Ohm/300mA
FB1227 9965 000 45219 Bead 600 Ohm/300mA
FB1228 9965 000 45218 Bead 10 Ohm/500mA
FB1231 9965 000 45219 Bead 600 Ohm/300mA
FB4201 9965 100 02512 Bead 100 Ohm 3A
FB4401 9965 000 45221 Bead 120Ohm/600mA
FB4402 9965 000 45221 Bead 120Ohm/600mA
FB4403 9965 000 45221 Bead 120Ohm/600mA
FB4404 9965 000 45221 Bead 120Ohm/600mA
FB4405 9965 000 45221 Bead 120Ohm/600mA
FB4406 9965 000 45221 Bead 120Ohm/600mA
FB4407 9965 000 45221 Bead 120Ohm/600mA
FB4408 9965 000 45221 Bead 120Ohm/600mA
FB6201 9965 100 02512 Bead 100 Ohm 3A
FB6202 9965 100 02512 Bead 100 Ohm 3A
FB6301 9965 100 02512 Bead 100 Ohm 3A
FB6302 9965 100 02512 Bead 100 Ohm 3A
FB6303 9965 100 02512 Bead 100 Ohm 3A
FB6304 9965 100 02512 Bead 100 Ohm 3A
FB6307 9965 100 02512 Bead 100 Ohm 3A
FB6308 9965 100 02776 Bead 120 Ohm 3A
FB7101 9965 100 02776 Bead 120 Ohm 3A
FB7206 9965 100 02512 Bead 100 Ohm 3A
FB7209 9965 100 02512 Bead 100 Ohm 3A
FB7210 9965 100 02512 Bead 100 Ohm 3A
FB7211 9965 100 02512 Bead 100 Ohm 3A
FB7212 9965 100 02512 Bead 100 Ohm 3A
X4101 9965 000 45243 Crystal 10Mhz 30pF
X4101 9965 100 04059 Crystal 10Mhz 30pF
X4101 9965 100 04060 Crystal 10Mhz 30pF
X4201 9965 100 02530 Crystal 28.322Mhz 14pF
X4201 9965 100 04057 Crystal 28.322Mhz 14pF
X4201 9965 100 04058 Crystal 28.322Mhz 14pF
X6201 9965 100 05957 Crystal 28.432Mhz 12pF
X6201 9965 100 05958 Crystal 28.432Mhz 12pF
ZD1103 9965 000 35994 BAV99
ZD1103 9965 100 05726 BAV99
ZD1104 9965 000 35994 BAV99
ZD1104 9965 100 05726 BAV99
ZD5101 9965 000 45246 PESD0603-140
ZD5102 9965 000 45246 PESD0603-140
ZD5103 9965 000 45246 PESD0603-140
ZD5104 9965 000 45246 PESD0603-140
ZD5105 9965 000 45246 PESD0603-140
ZD5106 9965 000 45246 PESD0603-140
ZD7101 9965 000 44282 BZX84-C5V6
ZD7101 9965 100 02526 BZX84-C5V6
ZD7102 9965 000 44282 BZX84-C5V6
ZD7102 9965 100 02526 BZX84-C5V6
ZD7103 9965 000 44282 BZX84-C5V6
ZD7103 9965 100 02526 BZX84-C5V6
ZD7104 9965 000 44282 BZX84-C5V6
ZD7104 9965 100 02526 BZX84-C5V6
ZD7105 9965 000 44282 BZX84-C5V6
ZD7105 9965 100 02526 BZX84-C5V6
ZD7106 9965 000 44282 BZX84-C5V6
ZD7106 9965 100 02526 BZX84-C5V6
ZD7107 9965 000 44282 BZX84-C5V6
ZD7107 9965 100 02526 BZX84-C5V6
ZD7201 9965 000 37806 SMD
g
C1101 9965 000 43488 100nF 25V 0603
C1102 9965 000 43488 100nF 25V 0603
C1103 9965 000 45199 4.7uF 10% 10V
C1105 9965 000 43488 100nF 25V 0603
C1107 9965 000 42231 330pF 50V NPO 0603
C1108 9965 000 42231 330pF 50V NPO 0603
C1110 9965 000 42401 220pF NP0 50V 5% 0603
C1111 9965 000 42230 33pF 50V 0603
C1112 9965 100 02500 220nF 10% 10V
C1114 9965 000 43488 100nF 25V 0603
C1115 9965 000 45199 4.7uF 10% 10V
C1116 9965 000 43978 10pF 5% 50V 0603
C1117 9965 000 43978 10pF 5% 50V 0603
C1120 9965 000 43488 100nF 25V 0603
C1121 9965 000 43488 100nF 25V 0603
C1122 9965 000 43488 100nF 25V 0603
C1123 9965 000 43488 100nF 25V 0603
C1124 9965 000 43488 100nF 25V 0603
C1201 9965 000 45200 1000 uF 25V
C1201 9965 100 04043 1000uF 20%
