Technical Specifications, Connections, and Chassis Overview
EN 4 LC4.3U AA1.
1.3 Chassis Overview
Figure 1-5 Chassis overview
F_15270_002.eps
2450505
SMALL SIGNAL BOARD
B
CLASS D AUDIO
AMPLIFIER PANEL
C
KEYBOARD CONTROL
PANEL
E
LCD PANEL
POWER SUPPLY
PANEL
LED & IR PANEL
J
SIDE I/O PANEL
G
