Philips 32PFL3007 - Page 50

EN 50TPM9.1A LA 10.
Circuit Diagrams and PWB Layouts
2012-Jun-15
back to
div. table
10-1-13 B13, POP Killer & Extender
19330_512_120606.eps
120606
POP Killer & Extender
B13 B13
2012-04-24
B
715G5617
POP Killer & Extender
POP_MUTE#
AMP_PD#
A_MUTE
AVDD3V3_HP
POP Killer Output
POP_MUTE#
H : Un-mute
L : Mute
H: UN-MUTE
L: MUTE
HPHONE_EN
For AC-on POP noise
For DC-on/off POP noise
V_MUTE
A_MUTE
H: UN-MUTE
L: MUTE
V_MUTE
D603
BAT54C
Q604
PMBS3904
R642
10K 1/16W 5%
Q606
PMBS3904
C603
100N 50V
R624
2.2K 1/16W
R665
NC/100R 1/16W 5%
C604
1uF 16V
R625
10K 1/16W 5%
R619
10K 1/16W 5%
1
2 3
Q609
PMBS3906
R626
1K 1/16W 5%
R638
47K 1/16W 5%
R622
100R 1/16W 5%
R623
470OHM1/10W
R628
10K 1/16W 5%
R621
470K 1/16W 5%
D601
NC/1N4148W
Q607
PMBS3904
D602
BAT54C
R630
NC/100R 1/16W 5%
Q605
PMBS3904
1
2 3
Q603
PMBS3906
Q602
PMBS3904
R627
1K 1/16W 5%
R618
47K 1/16W 5%
R629
1K 1/16W 5%
R643
10K 1/16W 5%
Q601
PMBS3904
R620
10K 1/16W 5%
DVDD3V3_AMP
1 3
ZD601
BZX84C3V6
V_MUTE
V_MUTE
5V_SW+12V 5VSB
5V_SW V_MUTE+12V5VSB
POP_MUTE# 4,18
HPHONE_EN 19
GND 4,5,6,7,8,9,10,11,12,13,14,15,17,18,19,20,21,22,23,24
HPHONE_EN
H: ON
L: Power Down
