Philips 32PFL3007 - Revision List; Technical Specifications, Diversity, and Connections; Technical Specifications; Directions for Use

Revision List
EN 2 TPM9.1AL LA1.
2012-Jun-15
back to
div. table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1
Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 9 10 11
Connection Overview
Mechanics Block Diagrams Schematics
Styling Wire Dressing Rear Cover Removal SSB Removal Wiring Diagram Block Diagram SSB J (IR/LED) E (Keyboard/Leading Edge)
32PFL3007/56 2-1 4-1 4.3.1 4.3.4 9.1 9.3 10.1 10.2 10.3 11.1
32PFL3007/98 2-1 4-1 4.3.1 4.3.4 9.1 9.3 10.1 10.2 10.3 11.1
32PFL3007S/98 2-1 4-1 4.3.1 4.3.4 9.1 9.3 10.1 10.2 10.3 11.1
42PFL3007/56 2-1 4-2 4.3.1 4.3.4 9.2 9.3 10.1 10.2 10.3 11.2
42PFL3007/98 2-1 4-2 4.3.1 4.3.4 9.2 9.3 10.1 10.2 10.3 11.2
42PFL3007S/98 2-1 4-2 4.3.1 4.3.4 9.2 9.3 10.1 10.2 10.3 11.2
