Philips 32PFL5007/V7 - 3 Antenna and External Equipment Connection; Video Input

RF
L1
YPbPr1
AV1
Av1R1
ANT IN
1. The aerial cable should not be bundled to the power cord.
COMPONENT (YCbCr/YPbPr) DVD INPUT
1. Connect the component outputs (YCbCr / YPbPr) of
DVD player to the component (YPbPr) input of the
the TV.
2. Connect audio outputs (L,R) of a DVD player to the
audio input (YPbPr) respectively.
3. Press the PLAY button on the DVD player.
VIDEO INPUT
1. Connect the component outputs VIDEO out
of VCR/Cable receiver to AV1, AV2.
2. Connect audio outputs (L, R) of a DVD player to the
audio input AV1, AV2 respectively.
3. Press the PLAY button on the VCR.
Note : Selecting a Source
Press SOURCE key on remote or on front panel keypad.
Press TV key on the remote to enter into TV source from any other source,
3 Antenna and External Equipment Connection
A source OSD will appear. Press Up/Down key on the remote or CH+ /CH- on
or VOL’+' key from front panel to enter selected source or press SOURCE key
repeatedly to change and select source.
front panel can be used to select source. Press OK/Right key on the remote
except USB source.
ent such as VCR,DVD player
EN 5
RF
AV OUT
AV OUT
RF
