EN 236TPM14.2E LA 11.
Styling Sheets
2014-Sep-26
back to
div.table
11.24 6800 series 50"
19616_801.eps
6800 series 50"
Pos No. Description Remarks
0040 Rear cover
0050 Stand Assembly
1050 Display panel
1053 Panel SSB
1054 Power Supply Unit
1056 IR/LED panel
1057 Keyboard control panel
1176 Remote control Not displayed
1184 Speakers
WiFi01 WiFi_USB
FOR ELECTRICAL PARTS/ASSEMBLIES SEE WIRING DIAGRAM CHAPTER 9
0040
1054
1184
1057
1050
WiFi01
1056
1184
0050
1053
