Alignments
EN 63TPM14.2E LA 6.
2014-Sep-26
back to
div. table
6.5 Reset of Repaired SSB
A very important issue towards a repaired SSB from a Service
repair shop (SSB repair on component level) implies the reset
of the NVM on the SSB.
A repaired SSB in Service should get the service Set type
“00PF0000000000” and Production code “00000000000000”.
Also the virgin bit is to be set. To set all this, you can use the
ComPair tool or use the “NVM editor” and “Dealer options”
items in SAM (do not forget to “store”).
After a repaired SSB has been mounted in the set (set repair
on board level), the type number (CTN) and production code of
the TV has to be set according to the type plate of the set. For
this, you can use the NVM editor in SAM. The loading of the
CTN and production code can also be done via ComPair
(Model number programming).
In case of a display replacement, reset the “Operation hours
display” to “0”, or to the operation hours of the replacement
display.
Remark:
- After the NVM has been replaced, go to SAM and scroll to the
<Reload MAC address> (see figure 1*).
- Select the item and press <OK> on the RC.
6.5.1 Reset of Repaired SSB
Instruction
After NVM replacement, reload MAC address via SAM
menu.This ensures the correct MAC address to be available in
CSM for future repair actions.
Way of working:
• After the NVM has been replaced, go to SAM and scroll to
the <Reload MAC address>.
• Select the item and press <OK> on the RC.
Notes:
• Only applicable to all related models that are “Smart TV
level 0”enabled (only YouTube access). For models
without internet connection feature, no action is needed.
40PFS5709/12 TPT400LA-HM06 SC1D 062
40PFK5709/12 TPT400LA-HM06 SC1D 062
40PFK6409/12 TPT400LA-HF05 066
40PFS6409/12 TPT400LA-HF05 066
40PFH6609/88 TPT400LA-HF05 066
40PFK6609/12 TPT400LA-HF05 066
40PFS6609/12 TPT400LA-HF05 066
40PFK6719/12 TPT400LA-HF05 SC1E 094
40PFS6719/12 TPT400LA-HF05 SC1E 094
40PUK6809/12 V400DK1-KS1 231
40PUS6809/12 V400DK1-KS1 231
40PUS6809/60 V400DK1-KS1 231
40PFK6909/12 LTA400HW02-G01 SZ SEC 120
40PFS6909/12 LTA400HW02-G01 SZ SEC 120
40PFK6949/12 LTA400HW02-G01 SZ SEC 120
40PFK6959/12 LTA400HW02-G01 SZ SEC 120
40PFK6989/12 LTA400HW02-G01 SZ SEC 120
42PFK6549/12 TPT420H2-DUJSGK 064
42PFK6559/12 TPT420H2-DUJSGK 064
42PFK6589/12 TPT420H2-DUJSGK 064
42PFK7109/12 TPT420H2-DUKSGK 073
42PFS7109/12 TPT420H2-DUKSGK 073
42PFK7179/12 LC420EUF-PGF1 077
42PFK7189/12 LC420EUF-PGF1 077
42PFS7189/12 LC420EUF-PGF1 077
42PFK7199/12 LC420EUF-PGF1 077
42PFS7199/12 LC420EUF-PGF1 077
42PFS7309/60 LC420EUF-PGF1 077
42PFK7509/12 LC420EUF-PGF1 077
42PFS7509/12 LC420EUF-PGF1 077
47PFK6649/12 TPT470H1-DUJSGK 065
47PFK6559/12 TPT470H1-DUJSGK 065
47PFK6589/12 TPT470H1-DUJSGK 065
47PFK7109/12 TPT470H1-DUKSGK 074
47PFS7109/12 TPT470H1-DUKSGK 074
47PFK7179/12 LC470EUF-PGF1 078
47PFK7189/12 LC470EUF-PGF1 078
47PFS7189/12 LC470EUF-PGF1 078
47PFK7199/12 LC470EUF-PGF1 078
47PFS7199/12 LC470EUF-PGF1 078
47PFS7309/60 LC470EUF-PGF1 078
47PFK7509/12 LC470EUF-PGF1 078
47PFS7509/12 LC470EUF-PGF1 078
48PFS5709/12 TPT480LS-HN03 SC1D 103
48PFK5709/12 TPT480LS-HN03 SC1D 103
48PFK6409/12 TPT480LS-HJ02 067
48PFS6409/12 TPT480LS-HJ02 067
48PFH6609/88 TPT480LS-HJ02 067
48PFK6609/12 TPT480LS-HJ02 067
48PFS6609/12 TPT480LS-HJ02 067
48PFK6719/12 TPT480LS-HJ02 SC3A 095
48PFS6719/12 TPT480LS-HJ02 SC3A 095
48PFK6909/12 LTA480HW03-G01 SZ SEC 121
48PFS6909/12 LTA480HW03-G01 SZ SEC 121
48PFK6949/12 LTA480HW03-G01 SZ SEC 121
48PFK6959/12 LTA480HW03-G01 SZ SEC 121
48PFK6989/12 LTA480HW03-G01 SZ SEC 121
50PUK6809/12 V500DK2-KS1 232
50PUS6809/12 V500DK2-KS1 232
50PUS6809/60 V500DK2-KS1 232
55PFS5709/12 TPT550J1-DUJSGE S1A 063
55PFK5709/12 TPT550J1-DUJSGE S1A 063
55PFK6409/12 TPT550J1-HJ05 072
55PFS6409/12 TPT550J1-HJ05 072
55PFH6609/88 TPT550J1-HJ05 072
CTN_ALT BOM# Panel Type Display Code
55PFK6549/12 TPT550J1-DUJSGK S1A 071
55PFK6559/12 TPT550J1-DUJSGK S1A 071
55PFK6589/12 TPT550J1-DUJSGK S1A 071
55PFK6609/12 TPT550J1-HJ05 072
55PFS6609/12 TPT550J1-HJ05 072
55PFK6909/12 LTA550HW04-G01 SZ SEC 122
55PFS6909/12 LTA550HW04-G01 SZ SEC 122
55PFK6949/12 LTA550HW04-G01 SZ SEC 122
55PFK6959/12 LTA550HW04-G01 SZ SEC 122
55PFK6989/12 LTA550HW04-G01 SZ SEC 122
55PFK7109/12 TPT550H2-DUKSGK S1A 075
55PFS7109/12 TPT550H2-DUKSGK S1A 075
55PFK7179/12 LC550EUF-PGF1 079
55PFK7189/12 LC550EUF-PGF1 079
55PFS7189/12 LC550EUF-PGF1 079
55PFK7199/12 LC550EUF-PGF1 079
55PFS7199/12 LC550EUF-PGF1 079
55PFS7309/60 LC550EUF-PGF1 079
55PFK7509/12 LC550EUF-PGF1 079
55PFS7509/12 LC550EUF-PGF1 079
58PUK6809/12 V580DK2-KS1 233
58PUS6809/12 V580DK2-KS1 233
58PUS6809/60 V580DK2-KS1 233
65PFK5909/12 V650HP1-LS6 E8 NH CMI 119
65PFS5909/12 V650HP1-LS6 E8 NH CMI 119
65PFS6659/12 TPT650LS-HQ01 SC1A 093
65PFS7559/12 TPT650LS-HQ01 SC1A 076
CTN_ALT BOM# Panel Type Display Code
