Philips 32PHS4032/12 - Page 91

8-9-2 PDIF/UART INPUT
SPDIF_OUT
U-ART
ZD109
NC/AZ5123-01H
1 2
C1002 120pF 50V
Grounding
Grounding
ZD462
AZ5123-01H
1 2
ZD461
AZ5123-01H
1 2
DV33
C1004
100NF 16V
R1003
10K
R1004
100OHM
DV33
PWR_12V
GND
DV15
DV33SB
PWR_12V 4,11,13,17
DV33SB 4,6,10,12,18
DV33 4,10,11,12,13,14,17,19
DV15 4,12
GND 4,6,7,8,9,10,11,12,13,14,15,16,17,18,19
AUDIO /IF
MIPS/UART/I2C/ICE
R4604
100OHM
R4605
100OHM
MIPS_RXB
MIPS_TXB
SPDIF_OUT
MIPS_RXB 11,16,18
AUDIO /IF
VGA_RIN
MIPS_TXB 11,16,18
SPDIF_OUT 7
VGA_LIN
VGA_LIN 7,16
VGA_RIN 7,16
CN118
3P
GND
1
VCC
2
VIN
3
GND
4
GND
5
NEAR SCALER IC
CN410
1
2
3
R1019
4K7 1/16W 5%
TP403
MIPS_RXB
MIPS_TXB
MIPS_RXB 11,16,18
MIPS_TXB 11,16,18
R1020
4K7 1/16W 5%
TP401
MIPS_TXB
TP402
DV33
CN117
NC/RCA JACK
1
2
SPDIF Out(Co-Layout)
SPDIF_OUT
R1014
NC/220 OHM
R1015
NC/75 OHM +-5% 1/16W
C1001
NC/100N16V
MIPS_RXB
