Philips 42PFL3604/12 - 2.3.2 Rear Connections; 2.4 Chassis Overview

Technical Specifications, Connections
EN 4 TPS2.2E LA2.
2009-May-29
9 - D0- Data channel j
10 - CLK+ Data channel j
11 - Shield Gnd H
12 - CLK- Data channel j
13 - n.c.
14 - n.c.
15 - DDC_SCL DDC clock j
16 - DDC_SDA DDC data jk
17 - Ground Gnd H
18 - +5V j
19 - HPD Hot Plug Detect j
20 - Ground Gnd H
2.3.2 Rear Connections
4 - Service / UART
1 - Ground Gnd H
2 - UART_TX Transmit k
3 - UART_RX Receive j
5 - Audio - In: Left / Right, HDMI / DVI
Gn - Audio L/R in 0.5 V
RMS
/ 10 kW jq
6 - TV ANTENNA - In
Signal input from an antenna, cable or satellite.
7 - Cinch: S/PDIF - Out
Bk - Coaxial 0.4 - 0.6V
PP
/ 75 W kq
8 - EXT1 - 2: Video RGB/YC - In, CVBS - In/Out, Audio -
In/Out
Figure 2-3 SCART connector
1 - Audio R 0.5 V
RMS
/ 1 kΩ k
2 - Audio R 0.5 V
RMS
/ 10 kΩ j
3 - Audio L 0.5 V
RMS
/ 1 kΩ k
4 - Ground Audio Gnd H
5 - Ground Blue Gnd H
6 - Audio L 0.5 V
RMS
/ 10 kΩ j
7 - Video Blue/C-out 0.7 V
PP
/ 75 Ω jk
8 - Function Select 0 - 2 V: INT
4.5 - 7 V: EXT 16:9
9.5 - 12 V: EXT 4:3 j
9 - Ground Green Gnd H
10 - Easylink P50 0 - 5 V / 4.7 kΩ jk
11 - Video Green 0.7 V
PP
/ 75 Ω j
12 - n.c.
13 - Ground Red Gnd H
14 - Ground P50 Gnd H
15 - Video Red/C 0.7 V
PP
/ 75 Ω j
16 - Status/FBL 0 - 0.4 V: INT
1 - 3 V: EXT / 75 Ω j
17 - Ground Video Gnd H
18 - Ground FBL Gnd H
19 - Video CVBS 1 V
PP
/ 75 Ω k
20 - Video CVBS/Y 1 V
PP
/ 75 Ω j
21 - Shield Gnd H
9 - EXT3: Video YPbPr - In, Audio - In
Gn - Video - Y 1 V
PP
/ 75 W jq
Bu - Video - Pb 0.7 V
PP
/ 75 W jq
Rd - Video - Pr 0.7 V
PP
/ 75 W jq
Wh - Audio - L 0.5 V
RMS
/ 10 kW jq
Rd - Audio - R 0.5 V
RMS
/ 10 kW jq
10 - HDMI 1: Digital Video, Digital Audio - In
See 3 - HDMI: Digital Video, Digital Audio - In
.
2.4 Chassis Overview
Refer to 9. Block Diagrams for PWB/CBA locations.
21
20
1
2
10000_001_090121.eps
090121
