7.Electrical Diagram
7.1 Block diagram
7.2 Power Supply
Power architecture of this platform.
Platform
MT5599
CN1190
12V
12V
AUDIO
AMP
LVDS
Display power
CN8601
CN9102 for OLED
Platform power
DIM
ON/OFF
PS_ON
12V
12V_A
PFC
AC-input +
Main fil
ter
AC IN
