Philips 43PUS7505/12 User Manual

9.Circuit Diagrams
9.1 A 715GA052 PSU(For 43”/50” /58” 75x5 & 58” 7605 Series)
9-1-1 AC Input
F9901
NC / 5A 250V
T5 A H/ 2 50 V
D9901
PG4007
R9904 NC R9903 NC
R9902 750K
!
!
!
N
SG9902
Spark Gap 500V
Rsen-
HS9901
NC / HEAT SINK
1
2
RV9901
620V
-
+
BD9901
TS10P06G-05
2
1
3
4
T5 A L/ 2 50 V
L9901
17mH
1 2
4 3
L9902
17mH
1 2
4 3
FB9902
BEAD
1 2
!
!
! !
!
!
!
SG9901
Spark Gap 500V
t
NR9902
1R5
12
!
F9902
5A 250V
CN9901
AC 2P
12
3
4
BR
FB9901
BEAD
1 2
C9911
22pF 250V
C9901 470NF 275V
C9902
470NF 275V
CN9905
NC
1
2
Vsin
C9912
22pF 250V
!
!
!
!
!
!
! !
!
!
!
!
L
R9905 750K R9906 750K
N
C9914
220PF 250V
R9901 750K
C9913
220PF 250V
L
t
NR9901
1R5
12
U9901
CAP200DG-TL
NC
1
D1
2
D1
3
NC
4
NC
5
D2
6
D2
7
NC
8

Philips 43PUS7505/12 Specifications

General

Screen Size	43 inches
Resolution	4K UHD (3840 x 2160)
Display Technology	LED
Smart TV	Yes
Operating System	SAPHI
Audio Output	20 W
HDMI Ports	3
USB Ports	2
VESA mounting	200 x 200 mm
Refresh Rate	60 Hz
HDR	Yes
Wireless LAN	Yes
Bluetooth	Yes
