Page #10 background imageLoading...
Page #10 background image
Net TV
Net TV offers Internet Services for your TV. Use the TV
Remote Control to browse the Net TV pages. You can
Play Movies, listen to Music and much more, all from
your TV screen.
Because Net TV is an Online System, it can be Modified over
time to better serve its purpose.
Some Net TV Services can be added, changed or stopped
after some time.
You cannot Download and Save Files or Install Plug-ins.
Before Using Net TV
Follow the procedure below before using Net TV.
1
Connect this Unit to the Internet.
2
Set up the necessary Network Connection Settings.
(Refer to Network
p. .)
Using Net TV
1
Press NETTV.
Net TV screen will appear, then use
to Select
Service Icon.
For the first time only, Terms of Use screen will appear.
After confirming the content, use
to Select Agree,
then press OK.
Guide to Net TV Menu Screen
Net TV Start Screen
4
3
5
21
6
Country: USA
Terms of UseOption
Featured AppsNow on TV
Now on TV
:
Displays the image of the Input
under present Tuning.
Featured Apps
:
Displays fixed net service icons.
Selected Apps
:
Displays movable net service icons.
Country
:
Selects what Country you live in.
Terms of Use
:
Displays a copy of Net Service.
Option
:
Remove or move App.
Information on Network Services
For detailed Information on 3rd party Internet Services,
please visit the Service Providers Website:
Netflix
:
http://www.netflix.com
VUDU
:
http://www.vudu.com
CinemaNow
:
http://www.cinemanow.com
For additional help, refer to the Frequently Asked
Questions FAQs at www.philips.com/support.
Select TV and enter your Model Number.
Changing Picture and Sound Settings
You must set Home in Location.
p. 
Otherwise, personalized Picture and Sound settings
will not be memorized after the Unit goes into Standby
Mode.
Changing Picture Settings
1
Press
and use
to Select Setup, then press OK.
2
Use to Select TV settings, then press OK.
3
Use to Select Picture, then press OK.
Accessibility
Mode selection
Picture format
Advanced settings
Pixel Plus Ultra HD
Sharpness
Tint
Color
Brightness
Contrast
Backlight
Auto picture
Installation
Features
Sound
Vertical position
Horizontal position
4
Use to Select the item you want to adjust, then
press OK.
Auto picture
to Select the desired Setting, then press OK
(Personal, Standard, Natural, Vivid, Sports,
Movie, Game, Energy saving and Internet video)
Cursor
Cursor
Backlight
to Reduce Power
Consumption and
Brightness
to Increase Power
Consumption and
Brightness
Contrast to Decrease Contrast to Increase Contrast
Brightness to Decrease Brightness to Increase Brightness
Color
to Decrease Color
Intensity
to Increase Color
Intensity
Tint to Add Green to Add Red
Sharpness to Soften to Sharpen
Pixel Plus Ultra HD
Enters sub-menus to adjust the following settings:
(Dynamic contrast, Color enhancement, Black
stretch, 120 PMR, 4K UHD Upscaling, Macro
Dimming, Noise reduction and MPEG artifact
reduction)
Advanced settings
Enters sub-menus to adjust the following settings:
(Color alignment, Custom color management,
HDR mode, Gamma, Blue stretch and Film
mode)
Picture format
Automatic
Changing Picture
Format
p. 
Super zoom
4:3
Movie expand 14:9
Movie expand 16:9
Wide screen
Full
Unscaled
Mode selection
PC
to Turn Off image
enhancement features
which makes the TV to
act purely as a monitor
HDTV
to enable image
enhancement features
to improve picture
quality
To obtain a more detailed electronic copy of this User Manual or to access live chat support, go to www.philips.com/support
10
Continued on next page.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 50PFL5602 and is the answer not in the manual?

Philips 50PFL5602 Specifications

General IconGeneral
Screen shapeFlat
Response time9.5 ms
Display diagonal50 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate60 Hz
Supported video modes480i, 480p, 720p, 1080i, 1080p, 2160p
Contrast ratio (typical)5000:1
Display diagonal (metric)127 cm
Screen format adjustments4:3, 14:9, 16:9, Zoom
Supported graphics resolutions640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Motion interpolation technologyPMR (Perfect Motion Rate) 120 Hz
EqualizerYes
RMS rated power20 W
Number of speakers2
Equalizer bands quantity5
AC input voltage120 V
AC input frequency50 Hz
Power consumption (standby)0.5 W
Power consumption (typical)125 W
On/off switch-
Product colorBlack
Panel mounting interface300 x 200 mm
3DNo
Audio formats supportedAAC, AC3, MP3
Image formats supportedJPG
Video formats supportedAVC, H.264, H.265, HEVC, MPEG1, MPEG2, MPEG4
RF connector typeF
RF ports quantity1
HDMI ports quantity3
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)EasyLink
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Tuner typeAnalog & digital
Supported TV bandsUHF, VHF
Analog signal format systemNTSC
Digital signal format systemATSC
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating temperature (T-T)5 - 40 °C
Package typeBox
Package depth162.6 mm
Package width1300.5 mm
Package height746.8 mm
Package weight13517.1 g
Music appsPandora
Video appsNetflix, YouTube
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)228.6 mm
Height (with stand)701.04 mm
Weight (with stand)10115.11 g
Depth (without stand)88.9 mm
Width (without stand)1122.7 mm
Height (without stand)662.9 mm
Weight (without stand)9797.6 g
