1.6. Operating Instructions of Edge Alignment Kit
1.6.1. Installing the Edge Alignment Kit
• Before installing the edge alignment kit, the display must be mounted to the frame of video wall correctly.
• Use the provided thumb screw
to install
the edge alignment kit.
• Use the “Edge Alignment Kit-1” for four adjacent displays.
Display 1 Display 2
Display 3 Display 4
2
3
4
5
6
7
8
1
• Use the “Edge Alignment Kit-2” for two adjacent displays.
Display 1 Display 2
1
3
4
NOTE: When installing the edge alignment kit, please consult a professional technician for proper installation. We accept no
liability for installations not performed by a professional technician.
