4-1 PL10.8DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
2. Disassembly Method
Note:
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
H = Hex Screw, CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Table."
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
[1]
Stand
Assembly
D1 4(S-1) ---
[2]
Rear
Cabinet
D1 16(S-2), 3(S-3) ---
[3] Shield Box
D2
D5
2(S-4), 12(S-5), 2(H-1),
*CN3002, *CN3004,
*CN3801, *CN3802,
*CN4901, *CN4902,
Jack Holder(A),
Jack Holder(B)
---
[4]
Digital Main
CBA Unit
D2
D5
6(S-6) ---
[5]
Power
Supply
CBA Unit
D2
D5
11(S-7), *CN1, *CN4,
*CN5
---
[1] Stand
Assembly
[2] Rear Cabinet
[13] Function
CBA Unit
[14] Front Flare
[15] LCD Module
Assembly
[10] Speaker
[11] Stand
Bracket
[7] PCB Holder
(D), (U)
[8] Wall Mount
Bracket
[16] Front Cabinet
Assembly
[3] Shield Box
[12] IR Sensor
CBA Unit
[9] Speaker-S
[4] Digital Main
CBA Unit
[5] Power Supply
CBA Unit
[6] Jack PCB
Holder
[6]
Jack PCB
Holder
D3 6(S-8) ---
[7]
PCB Holder
(D), (U)
D3 6(S-9) ---
[8]
Wall Mount
Bracket
D3 8(S-10), 2(S-11) ---
[9] Speaker-S D4 2(S-12), Desolder ---
[10] Speaker D4 4(S-13) ---
[11]
Stand
Bracket
D4
2(S-14), 6(S-15),
2(S-16),
AC Inlet Holder
---
[12]
IR Sensor
CBA Unit
D4
D5
*CN4051,
Sheet(Sensor)
---
[13]
Function
CBA Unit
D4
D5
Function Knob,
Knob Frame,
Sheet(Key)
---
[14] Front Flare D4
15(S-17), 4(S-18),
Boss, Boss(T),
Boss(W)
---
[15]
LCD
Module
Assembly
D4 3(S-19) ---
[16]
Front
Cabinet
Assembly
D4 --------------- ---
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
