8-1 PL10.4TR
TROUBLESHOOTING
The power cannot be turned on.
FLOW CHART NO.1
Is 5V voltage supplied to Pin(6) of CN3002 on the
Digital Main CBA Unit?
Is 3V voltage supplied to Pin(3) of CN3002 on the
Digital Main CBA Unit?
Replace Power Supply CBA Unit.
Replace Power Supply CBA Unit.
Ye s
Ye s
Replace Digital Main CBA Unit.
Replace Digital Main CBA Unit.
No
No
Ye s
When pressing power switch on the unit, LED is lighting
or flashing?
See FLOW CHART NO.2 <The key operation is not
functioning.>
No
Ye s
When pressing power switch on the remote control unit,
LED is lighting or flashing?
See FLOW CHART NO.3 <No operation is possible
from remote control unit. (Operation is possible from
the unit.)>
No
Ye s
Ye s
Is 3.3V voltage supplied to Pin(3) of CN3004 on the
Digital Main CBA Unit?
No
Ye s
Check the line between Pin(1) of CN4001 and Pin(3)
of CN3004, and service it if defective.
Is 3.3V voltage supplied to Pin(1) of CN4001 on the
Function CBA Unit?
No
Replace Function CBA Unit.
Is the Pin(3) voltage of CN4001 0V when pressing
power switch?
No
Check the line between Pin(3) of CN4001 and Pin(6)
of CN3004, and service it if defective.
The key operation is not functioning.
FLOW CHART NO.2
No operation is possible from remote control unit. (Operation is possible from the unit.)
FLOW CHART NO.3
Is 3.3V voltage supplied to Pin(3) of CN40
52 on the
IR Sensor CBA Unit?
Check AL+3.3V line and service it if defective.
Ye s
Ye s
Replace IR Sensor CBA Unit.
No
Ye s
Is the "L" pulse sent out Pin(2) of CN4052 on the
IR Sensor CBA Unit?
No
Check CL3004 and service it if defective.
No
Is the "L" pulse sent out Pin(2) of CN3004 on the
Digital Main CBA Unit?
Replace Digital Main CBA Unit.
To Next Page
