WAVEFORMS
PL10.8WF11-1
Input: NTSC Color Bar Signal (with 1kHz Audio Signal)
WF1 ~ WF4 = Waveforms to be observed at
Waveform check points.
(Shown in Schematic Diagram.)
AUDIO
AUDIO
0.1V
0.1V
0.5m
0.5m
s
WF4
JK3004, JK3009
VIDEO-Pr
VIDEO-Pr
0.2V
0.2V
20
20
µ
s
JK3003, JK3008
WF3
VIDEO-Pb
VIDEO-Pb
0.2V
0.2V
20
20
µ
s
JK3002, JK3007
WF2
VIDEO-Y
VIDEO-Y
0.2V
0.2V
20
20
µ
s
JK3001, JK3006
WF1
