PARTS LIST [55PFL5505D/F7]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
FRONT CABINET ASSEMBLY A01R5UF 1EM025185
A2 REAR CABINET A01R5UF 1EM024857
A4 FUNCTION KNOB A01P5UF 1EM327097
A5 KNOB FRAME A01P5UF 1EM223763
A9 JACK HOLDER(A) 5K A01P5UF 1EM223750
A10 JACK HOLDER(B) 5K A01P5UF 1EM327099
A12# RATING LABEL A01R5UF ----------
A16 FRONT FLARE A01R5UF 1EM024858
A17 JACK LABEL-A A01P5UF 1EM430739
A18 JACK LABEL-B A01P5UF 1EM430740
A19 JACK LABEL-C A01P5UF 1EM430741
A22 STAND ASSEMBLY(SWIVEL) A01R5UF 1EMN26119
B1 SHIELD BOX 5K A01P5UF 1EM024855
B5 STAND BRACKET A01R5UF 1EM024865
B6 WALL MOUNT BRACKET A01R5UF 1EM124135
B8 PCB HOLDER(U) 40W5K A01P5UF 1EM223751
B9 PCB HOLDER(D) 40W5K A01P5UF 1EM223752
B10 AC INLET HOLDER 5K A01P5UF 1EM327102
B12 JACK PCB HOLDER A01R5UF 1EM124137
B18 GASKET(15X4X2) A01Q0UF 1EM430743
B28 BOSS(W) A01P5UF 1EM327100
B29 BOSS(T) A01P5UF 1EM327101
B31 GASKET(60X4XT2) A01P5UF 1EM430738
B41 SHEET(KEY) A01P5UF 1EM431457
B42 SHEET(SENSOR) A01P5UF 1EM431458
B49 BOSS A01R5UF 1EM430398
B52 CLOTH(10X30XT0.5) B5900UA 0EM404486
CL401 WIRE ASSEMBLY 14PIN 14PIN/410MM/RED
BLK
WX1A01R5-303
CL402 WIRE ASSEMBLY 10PIN-14PIN 10P-14P/
410MM/Y/B
WX1A01R5-304
CL601 WIRE ASSEMBLY 2PIN 2PIN/200MM/WHITE
BLK
WX1A01P5-308
CL3002 WIRE ASSEMBLY 14PIN 14PIN/150MM/RED
BLK
WX1A01R5-307
CL3004 WIRE ASSEMBLY 7PIN 7PIN/490MM/RED
BLACK
WX1A01R5-301
CL3801 WIRE ASSEMBLY 2PIN 2PIN/270MM/RED
BLACK
WX1A01R5-305
CL3802 WIRE ASSEMBLY 2PIN 2PIN/820MM/RED
BLACK
WX1A01R5-306
CL3803 WIRE ASSEMBLY 2PIN 2PIN/370MM/RED
BLACK
WX1A01R5-309
CL3804 WIRE ASSEMBLY 2PIN 2PIN/370MM/RED
BLACK
WX1A01R5-309
CL4001 WIRE ASSEMBLY 3PIN 3PIN/960MM/RED
BLACK
WX1A01R5-302
CL4901 WIRE ASSEMBLY 51PIN 51PIN/471MM WX1A01R5-102
CL4902 WIRE ASSEMBLY 41PIN 41PIN/471MM WX1A01R5-101
L5 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L12 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L13 HEX SCREW #4-40 7MM 1EM430139
L14 DOUBLE SEMS SCREW M5X20 M5X20 FPH35200
L16 ASSEMBLED SCREW (D16.5/M4X14)
A73F2FP
1EM425499
L17 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120
L20 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L22 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L30 SCREW P-TIGHT M4X18 BIND HEAD+ GBHP4180
L31 SCREW P-TIGHT 3X14 WASHER HEAD+ GCHP3140
L36 DOUBLESEMS SCREW M3X8 A01P7UH 1EM432184
LCD-1 LCD MODULE/55W LTA550HJ01 UDULCD0SM005
SP3801 SPEAKER MAGNETIC SB-05N43C DS06520XQ002
SP3802 SPEAKER MAGNETIC SB-05N43B DS06520XQ001
SP3803 SPEAKER MAGNETIC S025FH02 DS06220XQ001
SP3804 SPEAKER MAGNETIC S025FH02 DS06220XQ001
TH3101 THERMAL SHEET TMS-L-3 20X20HC XK10000X4009
TH3801 THERMAL SHEET TMS-L-3 7X7HC XK10000X4010
TH4201 THERMAL SHEET TMS-L-3 20X20HC XK10000X4009
PACKING
S1 CARTON(T) A01R5UF 1EM328141B
S2 CARTON(B) A01R5UF 1EM328144A
S3 STYROFOAM TOP A01R5UF 1EM025765
S4 STYROFOAM BOTTOM A01R5UF 1EM025766
S5 SET BAG A01R5UF 1EM328143
S6 SERIAL NO.LABEL A01Q0UF ----------
S11 STYROFOAM CENTER A01R5UF 1EM025767
S12 SET SHEET A01R5UF 1EM328337
ACCESSORIES
AC601# CORD W/O A GND WIRE UL/CSA/ 162/NO/
BLACK
WAV0162LW001
X1 OENERS MANUAL BAG A91H5UF 1EM429581
X2# OWNERS MANUAL A01P5UF 1EMN26019A
X3 REMOTE CONTROL UNIT YKF255-007 URMT42JHG002
X4 BATTERY R03-B500/01S XB0M451CZB01
X6 QUICK START GUIDE A01P5UF 1EMN26020
X7 REGISTRATION CARD A01P5UF 1EMN26042A
X8 CHILD SAFETY SHEET A91H5UF 1EMN25001
X10 WALL MOUNT INSTRUCTION A01P5UF 1EMN26041A
X11 CONNECTION GUIDE A01P5UF 1EM327858
X12 CABLE MANAGEMENT TIE(BLACK) A01F2UH 1EM431197
Ref. No. Description Part No.
