PARTS LIST [55PFL5706/F7 (Serial No.: DS1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A17R5UF 1EM027449A
A2 REAR CABINET A17R5UF 1EM027452A
A3 DECORATION PLATE A11R4UF 1EM125773
A5 KNOB FRAME A17P5UH 1EM225743
A8 JACK HOLDER A A11P4UH 1EM225303
A9 JACK HOLDER B A11P4UH 1EM329877
A12# RATING LABEL A17R9UH ----------
A14 LOGO LABEL A11P4UH ----------
A22 55W 5000 STAND ASSEMBLY A17R5UF 1EM027666
A23 JACK LABEL A A11P4UH 1EM433958
A24 JACK LABEL D A11P4UH 1EM433961
A32 FUNCTION BUTTON A11P4UH 1EM329857
A33 JACK LABEL B A11Q5UD 1EM435358
A34 JACK LABEL C A11P4UH 1EM433960
A42 ENERGY GUIDE LABEL A17R8UD ----------
B1 SHIELD BOX A11Q4UF 1EM027325
B5 STAND BRACKET 5K A17R5UF 1EM027772A
B10 AC INLET HOLDER 5K A01P5UF 1EM327102
B12 JACK PCB HOLDER 5K A17R5UF 1EM027768A
B18 GASKET A8AF0UH 1EM425861
B22 WALL MOUNT BRACKET A17R5UF 1EM126335A
B28 GASKET(60X4XT2) A01P5UF 1EM430738
B32 SHIELD PLATE A11P4UH 1EM329858
B44 PCB HOLDER(U) 55W A17R5UF 1EM126275
B45 PCB HOLDER(D) 40W A17P5UH 1EM126034
B50 FRC SHIELD BOX A11R4UF 1EM330040
CL1601 WIRE ASSEMBLY 2PIN 2PIN/180MM/WHITE
BLK
WX1A17R8-305
CL1801 WIRE ASSEMBLY 14PIN 14PIN/
130MM&190MM
WX1A17R8-301
CL1913 WIRE ASSEMBLY 10PIN 10PIN/450MM/RED
BLK
WX1A17R8-307
CL1914 WIRE ASSEMBLY 14PIN 14PIN/420MM/RED
BLK
WX1A17R8-306
CL3102 WIRE ASSEMBLY 7PIN 7PIN/400MM/RED
BLACK
WX1A17R8-302
CL3801 WIRE ASSEMBLY 4PIN 4PIN/675MM&400MM WX1A17R8-304
CL3901 WIRE ASSEMBLY 51PIN 51PIN/238MM WX1A17R8-113
CL4051 WIRE ASSEMBLY 2PIN 2PIN/925MM/RED
BLACK
WX1A17R8-303
CL5003 WIRE ASSEMBLY 51PIN 51PIN/455MM WX1A17R8-132
CL5004 WIRE ASSEMBLY 41PIN 41PIN/455MM WX1A17R8-131
TH3104 THERMAL SHEET TMS-14-20 12X12 XK10000X4011
TH5001 THERMAL SHEET TMS-L-2 25X25HC XK10000X4007
USB-1 WIRELESS LAN ADAPTOR AW-NU138 UWLUSBAZW001
L2 SCREW P-TIGHT 3X14 WASHER HEAD+ GCHP3140
L6 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L9 DOUBLE SEMS SCREW M8X18 M8X18 FPH38180
L19 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L38 SCREW S-TIGHT 3X8 WASHER HEAD+BLAC GCHS3080
LCD-1 TFT-LCD MODULE 55W LTA550HJ01-F03 UDULCD0SM030
SP3801 SPEAKER MAGNETIC BOX 8OHM/10W SB-
05N44H
DS08050XQ012
SP3802 SPEAKER MAGNETIC BOX 8OHM/10W SB-
05N44H
DS08050XQ012
PACKING
S1 CARTON A17R9UH 1EM331297
S3 STYROFOAM TOP A17R5UF 1EM027965
S4 STYROFOAM BOTTOM A17R5UF 1EM027966
S5 SET BAG(1500X1100) A11R5UD 1EM331039
S6 SERIAL NO. LABEL A01PBUH ----------
ACCESSORIES
AC601# CORD W/O A GND WIRE UL/CSA/ 162/NO/
BLACK
WAV0162LW001
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A17P5UH 1EMN28063
X3 REMOTE CONTROL UNIT YKF255-008 URMT42JHG003
X4 BATTERY R03-B500/01S XB0M451CZB01
X6 QUICK START GUIDE A17P5UH 1EMN27839
X7 REGISTRATION CARD(PHILIPS) A11P4UH 1EMN27321
X12 CABLE MANAGEMENT TIE(BLACK) A01F2UH 1EM431197
X13 NETFLIX GUIDE A01P8UH 1EMN26659
X19 STAND SCREW KIT A17R8UD 1ESA28787
X20 VUDU SHEET E5S20UD 1VMN30133
X23 NOTICE FLYER A11P4UH 1EMN27819
Ref. No. Description Part No.
