1 - - EXIT
To switch back to watch TV or to stop an interactive
TV application.
2 - Volume
Prese + or - to adjust the volume level.
3 - Number keys
To select a channel directly.
4 - AD
To access the Audio Description and toggle to switch
on and off. Long press to open programme info.
5 - Channel
Prese + or - to switch to the next or previous channel
in the channel list. To open the next or previous page
in Text/Teletext.
6 - Mute
To mute the sound or to restore it.
7 - OPTIONS
To open or close the options menu.
3.2
Pair Your Remote Control to
TV
This remote control uses both Bluetooth® and IR
(infrared) to send its commands to the TV.
• You can use this remote control via IR (infrared) for
most operations.
• To use advanced operation like voice search and
remote control keyboard, you need to pair (link) the
TV with the remote control.
When you start the initial TV installation, the TV
invites you to long press the PAIR (SOURCES) key,
and by doing so, the pairing will be done.
Note:
1 - Once the remote control has entered pairing
mode successfully, the blue LED indicator ring around
the microphone on the front side of the remote
control starts blinking.
2 - The remote control must be kept close to the TV
(within 1m distance) during pairing in order to ensure
success.
3 - If the TV does not launch the voice control
field when press , pairing was unsuccessful.
4 - It is advisable to wait until the set has fully started
up and launched all background processes before
pairing mode is entered as the toast message
containing further instructions may appear too late,
thereby negatively impacting the pairing procedure.
Pairing or pairing again
If the pairing with the remote control was lost, you
can pair the TV with the remote control again.
You can simply long press
the PAIR ( SOURCES) key (approximate for 3
seconds) for pairing.
Alternatively, go Settings > Wireless and networks
> Remote control > Pair remote control, then follow
the on-screen instructions.
A message appears when the pairing is successful.
Remote Control Software
Settings > Wireless and networks > Remote
control > Remote control info
Once the remote control is paired, you can check the
current remote control software version.
Settings > Wireless and networks > Remote
control > Update remote control software
Check available remote control software for updates.
3.3
Voice Search
You can search for videos, music or anything else on
the Internet by simply using your voice. You can
speak into the microphone on the remote control.
You need to pair the remote control to the TV before
use voice search.
To use Voice...
1 - Press on remote control, the blue light on the
remote control lights up and the search field
opens, the microphone is active.
2 - Speak out what you are looking for with clear
pronunciation. You can speak for 10 seconds before
the microphone switches off. It might take some time
for the results to appear.
3 - In the list of search results, you can select the
item you want.
9

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PML9507 and is the answer not in the manual?

Philips 55PML9507 Specifications

General IconGeneral
Color nameGun metal gray
Stand typeLegs stand
Product colorGray
Ambient lightingYes
Panel mounting interface300 x 200 mm
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Display diagonal (metric)139 cm
Supported graphics resolutions3840 x 2160
Display refresh rates supported60 Hz, 120 Hz
Motion interpolation technology-
Programming period8 day(s)
Game featuresAuto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Teletext standardsHyper-text
Audio formats supportedAAC, FLAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, HEIF, JPEG, PNG
Video formats supportedAVI, HEVC/H.265, MKV, MPEG1, MPEG2, MPEG4, VP9
Subtitle formats supportedASS, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) technologyDolby Vision, Filmmaker Mode, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Music appsSpotify, YouTube Music
Video appsAmazon Prime Video, Apple TV, BBC iPlayer, Disney+, YouTube
Smart modesIMAX Enhanced
Operating system versionTV 11
App distribution platformGoogle Play
Operating system installedAndroid
Tuner typeAnalog & digital
Analog signal format systemPAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Sound modesAI Sound
Audio decodersDTS, Dolby Atmos, Dolby Digital, DTS-HD, Dolby MS12
RMS rated power40 W
HDMI version2.0/2.1
PC in (D-Sub)No
RF ports quantity2
USB 2.0 ports quantity3
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version5.0
Cables includedAC
Package typeBox
Package depth840 mm
Package width1360 mm
Package height160 mm
Package weight24500 g
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Weight and Dimensions IconWeight and Dimensions
Stand depth279.6 mm
Stand width727 mm
Depth (with stand)254 mm
Width (with stand)1231.4 mm
Height (with stand)732 mm
Weight (with stand)19700 g
Depth (without stand)86.1 mm
Height (without stand)712 mm
Weight (without stand)19300 g
