1 - Press .
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Select Channel List and press OK.
5 - Select Filter Antenna Channels and press OK.
6 - In the Options menu, select the filter you want
and press OK to activate. The name of the filter
appears as part of the channel list name on top of the
channel list.
7 - Press (left) to go back one step or press to
close the menu.
5.4
Watching channels
Tune to a Channel
To start watching TV channels, press . The TV tunes
to the channel you last watched.
Switch Channels
To switch channels, press or .
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
To switch back to the previously tuned channel,
press Back.
You can also tune to channels from a Channel List.
Lock a Channel
Lock and Unlock a Channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
To lock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to lock.
4 - Press OPTIONS and select Lock
Channel and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it. A
locked channel is marked with a (lock).
6 - Press (left) to go back one step or
press Back to close the menu.
To unlock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to unlock.
4 - Press OPTIONS and select Unlock
Channel and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or
press Back to close the menu.
If you lock or unlock channels in a channel list, you
only have to enter the PIN code just once until you
close the channel list.
For more information, in Help, press the colour
key Keywords and look up Child Lock for more
information.
Parental Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age
rated. When the age rating of a programme is equal to
or higher than the age you have set as age rating for
your child, the programme will be locked. To watch a
locked programme, you must enter the Parental
Rating (only available for certain countries) code first.
To set an age rating…
1 - Select Settings > Child Lock > Parental
Rating and press OK.
2 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set Code in Child Lock. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
3 - Back in Parental Rating, select the age and
press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
To switch off the parental age rating, select None.
However, in some countries you must set an age
rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Channel Options
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
(analogue or digital) or depending on the TV settings
you made, some options are available. For example,
the Screen off option is only available for radio
channels. It is suggested to turn off the TV screen for
13

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PML9507 and is the answer not in the manual?

Philips 55PML9507 Specifications

General IconGeneral
Color nameGun metal gray
Stand typeLegs stand
Product colorGray
Ambient lightingYes
Panel mounting interface300 x 200 mm
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Display diagonal (metric)139 cm
Supported graphics resolutions3840 x 2160
Display refresh rates supported60 Hz, 120 Hz
Motion interpolation technology-
Programming period8 day(s)
Game featuresAuto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Teletext standardsHyper-text
Audio formats supportedAAC, FLAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, HEIF, JPEG, PNG
Video formats supportedAVI, HEVC/H.265, MKV, MPEG1, MPEG2, MPEG4, VP9
Subtitle formats supportedASS, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) technologyDolby Vision, Filmmaker Mode, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Music appsSpotify, YouTube Music
Video appsAmazon Prime Video, Apple TV, BBC iPlayer, Disney+, YouTube
Smart modesIMAX Enhanced
Operating system versionTV 11
App distribution platformGoogle Play
Operating system installedAndroid
Tuner typeAnalog & digital
Analog signal format systemPAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Sound modesAI Sound
Audio decodersDTS, Dolby Atmos, Dolby Digital, DTS-HD, Dolby MS12
RMS rated power40 W
HDMI version2.0/2.1
PC in (D-Sub)No
RF ports quantity2
USB 2.0 ports quantity3
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version5.0
Cables includedAC
Package typeBox
Package depth840 mm
Package width1360 mm
Package height160 mm
Package weight24500 g
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Weight and Dimensions IconWeight and Dimensions
Stand depth279.6 mm
Stand width727 mm
Depth (with stand)254 mm
Width (with stand)1231.4 mm
Height (with stand)732 mm
Weight (with stand)19700 g
Depth (without stand)86.1 mm
Height (without stand)712 mm
Weight (without stand)19300 g
