Circuit Descriptions
EN 43QM15.2E LA 7.
2015-Sep-30
back to
div.table
7.1.3 SSB Cell Layout
Figure 7-1 SSB layout cells (top view)
19880_200.eps
MT5580
DDR
HDMI
HDMI
TUNER
DC/DC
SAT
NETWORK
COMMON INTERFACE
USB
USB
Headphone
SCART
SERVICE
CONNECTOR
ANALOG I/O
SPDIF OUT
