Circuit Descriptions
EN 32 TPL16.1E LA7.
2016-Sep-23
back to
div.table
7.1.3 SSB Cell Layout
Figure 7-1 SSB layout cells (top view)
20110_200.eps
MT5596
DDR
HDMI
HDMI
TUNER
DC/DC
NETWORK
COMMON INTERFACE
USB
USB
Headphone
SCART
SERVICE
CONNECTOR
ANALOG I/O
SPDIF OUT
