Philips 55PUS6101 Service Manual

Revision List
EN 2 TPL16.1E LA1.
2016-Sep-23
back to
div.table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• Chapter 2: Updated table 2.1 Technical Specifications
.
• Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview
.
Manual xxxx xxx xxxx.2
• Chapter 2: Updated table 2.1 Technical Specifications
.
• Chapter 4: Added figures 4-2 Cable dressing (43" 6201
series), 4-5 Cable dressing (55" 6201 series) and 4-6
Cable dressing (65" 6121 series).
• Chapter 5: Updated table 5-3 Service mode overview
.
• Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview
.
• Chapter 7: Updated figure 7-2 Power Architecture
and
table 7-1 Connector overview
.
• Chapter 10: Added circuit diagrams 10.3 A 715G6887
PSU, 10.4 AD 715G7700 LED Driver board, 10.7 J
715G8527 IR/LED Panel, 10.8 J 715G8521 IR/LED Panel,
10.10 E 715G8555 Keyboard control panel10.11 AL
715G7004 Ambilight Board and 10.12 AL 715G6981
Ambilight Board.
• Chapter 11: Added styling sheets 11.2 6201 series 43"
,
11.5 6201 series 55"
and 11.6 6121 series 65".
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in back to
div.table 2-1. Here is product information available, as well as
getting started, user manuals, frequently asked questions and
software & drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 9 10 11
Connection Overview
Mechanics
Block Diagram
Schematics
Styling Wire Dressing Rear Cover Removal Kyboard Control Removal SSB Removal IR/LED Board Removal Power Supply SSB J (IR/LED) E (Keyboard/Leading Edge) AL(Ambilight Board)
43PUH6101/88 2-1 4-1 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.1 10.5 10.6 10.9 - 11.1
43PUS6101/12 2-1 4-1 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.1 10.5 10.6 10.9 - 11.1
43PUT6101/12 2-1 4-1 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.1 10.5 10.6 10.9 - 11.1
43PUT6101/60 2-1 4-1 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.1 10.5 10.6 10.9 - 11.1
43PUS6201/12 2-1 4-2 4-13 & 4-14 4-15 4-16 4-17 & 4-18 9.1 10.1 10.5 10.7 10.10 10.9 11.2
43PUT6201/12 2-1 4-2 4-13 & 4-14 4-15 4-16 4-17 & 4-18 9.1 10.1 10.5 10.7 10.10 10.9 11.2
49PUH6101/88 2-1 4-3 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.3
49PUS6101/12 2-1 4-3 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.3
49PUT6101/12 2-1 4-3 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.3
49PUT6101/60 2-1 4-3 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.3
55PUH6101/88 2-1 4-4 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.4
55PUS6101/12 2-1 4-4 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.4
55PUT6101/12 2-1 4-4 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.4
55PUT6101/60 2-1 4-4 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.2 10.5 10.6 10.9 - 11.4
55PUS6201/12 2-1 4-5 4-13 & 4-14 4-15 4-16 4-17 & 4-18 9.1 10.2 10.5 10.7 10.10 10.9 11.5
55PUT6201/12 2-1 4-5 4-13 & 4-14 4-15 4-16 4-17 & 4-18 9.1 10.2 10.5 10.7 10.10 10.9 11.5
65PUS6121/12 2-1 4-6 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.3 10.5 10.8 10.9 - 11.6
65PUT6121/12 2-1 4-6 4-7 & 4-8 4-9 4-10 4-11 & 4-12 9.1 10.3 10.5 10.8 10.9 - 11.6

Philips 55PUS6101 Specifications

General

Brand	Philips
Model	55PUS6101
Category	LCD TV
Language	English
