Alignments
EN 29TPL16.1E LA 6.
2016-Sep-23
back to
div.table
This group setting of colour temperature will be applied
automatically to the TV / VGA / HDMI / AV sources.
Note: The information of the RGB value is only for reference,
the specific value is based on model adjustment.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
MT5561 ICs is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE and press OK on the RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
6.4.2 Option Code Overview
Enter SAM mode to check the option codes. they could be
edited in the NVM.
6.4.3 Display Code Overview
Press the following key sequence on a standard RC
transmitter: “062598” directly followed by MENU and “xxx”,
where “xxx” is a 3 digit decimal value of the panel type: see
column “Display Code” in back to div.table 6-3
. After resetting
the Display Code, restart the set immediately.
Table 6-3 Display code overview
6.5 Reset of Repaired SSB
A very important issue towards a repaired SSB from a Service
repair shop (SSB repair on component level) implies the reset
of the NVM on the SSB.
A repaired SSB in Service should get the service Set type
“00PF0000000000” and Production code “00000000000000”.
Also the virgin bit is to be set. To set all this, you can use the
“NVM editor” and “Dealer options” items in SAM (do not forget
to “store”).
After a repaired SSB has been mounted in the set (set repair
on board level), the type number (CTN) and production code of
the TV has to be set according to the type plate of the set. For
this, you can use the NVM editor in SAM.
In case of a display replacement, reset the “Operation hours
display” to “0”, or to the operation hours of the replacement
display.
Remark:
- After the NVM has been replaced, go to SAM and scroll to the
<Reload MAC address> (see figure 1*).
- Select the item and press <OK> on the RC.
6.5.1 Reset of Repaired SSB
Instruction
After NVM replacement, reload MAC address via SAM
menu.This ensures the correct MAC address to be available in
CSM for future repair actions.
Way of working:
• After the NVM has been replaced, go to SAM and scroll to
the <Reload MAC address> .
• Select the item and press <OK> on the RC.
Notes:
• Only applicable to all related models that are “Smart TV
level 0”enabled (only YouTube access). For models
without internet connection feature, no action is needed.
• HDCP keys are located in the NVM.
New NVM EEPROMs are shipped with pre-loaded HDCP keys.
6.5.2 SSB Identification
SSB’s of this chassis are identified by a “715” code on the SSB.
Cool (11000K) 43PUH6101/88 118 123 128
43PUS6101/12 117 122 127
43PUT6101/12 116 123 125
43PUT6101/60 118 124 126
43PUS6201/12 125 127 126
43PUT6201/12 123 125 126
49PUH6101/88 120 127 121
49PUS6101/12 118 126 121
49PUT6101/12 118 125 123
49PUT6101/60 119 125 122
55PUH6101/88 122 117 127
55PUS6101/12 123 115 126
55PUT6101/12 123 116 125
55PUT6101/60 122 117 124
55PUS6201/12 122 118 124
55PUT6201/12 124 119 126
65PUS6121/12 121 122 127
65PUT6121/12 121 121 127
Warm (6500K) 43PUH6101/88 126 112 77
43PUS6101/12 125 113 78
43PUT6101/12 127 113 79
43PUT6101/60 126 112 80
43PUS6201/12 127 114 88
43PUT6201/12 126 113 87
49PUH6101/88 127 75 70
49PUS6101/12 125 77 69
49PUT6101/12 124 76 68
49PUT6101/60 123 78 71
55PUH6101/88 127 90 81
55PUS6101/12 125 91 80
55PUT6101/12 127 92 82
55PUT6101/60 126 93 82
55PUS6201/12 121 95 88
55PUT6201/12 122 96 89
65PUS6121/12 127 116 98
65PUT6121/12 126 115 97
Picture mode Screen size
Colour temperature
Red Green Blue
CTN_ALT BOM# Panel Type Display Code
43PUH6101/88 TPT430U3-EQYSHM.G S1G 213
43PUS6101/12 TPT430U3-EQYSHM.G S1G 213
43PUT6101/12 TPT430U3-EQYSHM.G S1G 213
43PUT6101/60 TPT430U3-EQYSHM.G S1G 213
43PUS6201/12 TPT430U3-EQYSHM.G S1H 217
43PUT6201/12 TPT430U3-EQYSHM.G S1H 217
49PUH6101/88 TPT490U2-EQYSHM.G SC1L 214
49PUS6101/12 TPT490U2-EQYSHM.G SC1L 214
49PUT6101/12 TPT490U2-EQYSHM.G SC1L 214
49PUT6101/60 TPT490U2-EQYSHM.G SC1L 214
55PUH6101/88 TPT550J1-QUBN0.K S8940D 215
55PUS6101/12 TPT550J1-QUBN0.K S8940D 215
55PUT6101/12 TPT550J1-QUBN0.K S8940D 215
55PUT6101/60 TPT550J1-QUBN0.K S8940D 215
55PUS6201/12 TPT550J1-QUBN0.K S8940L 218
55PUT6201/12 TPT550J1-QUBN0.K S8940L 218
65PUS6121/12 TPT650UA-QVN06.U S600C 216
65PUT6121/12 TPT650UA-QVN06.U S600C 216
