Philips 55PUS6101 Service Manual

Circuit Diagrams and PWB Layouts
EN 95TPL16.1E LA 10.
2016-Sep-23
back to
div.table
10.6 J 715G8151 IR/LED Panel
10-6-1 IR & LED & 3D & Light sensor
201100_532.eps
LED&IR&3D&Light sensor
J J
2015-12-07
715G8151
LED&IR&3D&Light sensor
RC_IRA
IR power
LED_R
RC-IR
RC_IRA
IR power
3V3SB
3V3SB
3V3SB
Red
IR Receiver
R201
10K 1/16W 5%
R201
10K 1/16W 5%
R212 10R 1/16W 5%R212 10R 1/16W 5%
C211
1UF 6.3V
C211
1UF 6.3V
R202
1K 1/16W 5%
R202
1K 1/16W 5%
Q201
BC847BW
Q201
BC847BW
R211
100R 1/16W 5%
R211
100R 1/16W 5%
U213
TSOP75436TR
U213
TSOP75436TR
GND
1
VCC
2
Vout
3
GND
4
C210
NC/ 1UF 6.3V
C210
NC/ 1UF 6.3V
LED201
GPSS008RC4
LED201
GPSS008RC4
12
CN201
CONN
CN201
CONN
1
2
3
4
5
67
U212
TSOP75436TR
U212
TSOP75436TR
GND
1
VCC
2
Vout
3
GND
4
