Circuit Descriptions
EN 35TPL16.1E LA 7.
2016-Sep-23
back to
div.table
7.3.1 Power layout SSB
Figure 7-4 Power SSB Top View
20110_208.eps
L803,+5V_USB
FB7056,+5V_SW
L707,DVDD3V3
/AVDD3V3
/VCC3.3V_FRC
L703, VCCK, 1.0V
C1113,+5V-USB
L701, DDRV, 1.5V
L702, +5V_STB
L803, VCC0.9V_FRC
