Connecting to your PC
Fast Charger
or
RJ45
PD 15W Charger
1 2
3 5 7
4
6
8
9
10
15
11
13
12
14
1
2
b
Thunderbolt
HDR Game
  

  


1
2
HDR Game
  



  
USB Type-A
USB Type-A
DP
HDMI
USB-C
OR
Multi-stream transport
Thunderbolt
1
Power Switch
2
AC power input
3
HDMI 1 input
4
HDMI 2 input
5
DisplayPort input
6
Thunderbolt
TM
4 input /
Thunderbolt
TM
4 output
• Thunderbolt
TM
4 input :
Video output (ALT mode DP 1�4), PD
90W, data transfer�
• Thunderbolt
TM
4 output : PD
15W, downstream�
• Thunderboltdaisychain:rstplug
in Thunderbolt input , then
plug in Thunderbolt output for
signal output�
(Refer to chapter: Daisy-chain
function)
7
USB upstream
8
RJ45 input
9
USB downstream
10
USB downstream
11
USB downstream/USB fast charger
12
USB downstream
13
USBC(PD 45W, downstream)
14
Audio out / microphone in combo
jack
15
Kensington anti-theft lock
Connect to PC
1. Connect the power cord to the back
of the display rmly.
2. Turn o your computer and unplug
its power cable.
3. Connect the monitor signal cable to
the video connector on the back of
your computer.
4. Plug the power cord of your
computer and your monitor into a
nearby outlet.
5. Turn on your computer and monitor.
If the monitor displays an image,
installation is complete.
