65BDL4650D/75BDL4650D/86BDL4650D
15
2.5. Mounting in Portrait Orientation
This display can be installed in portrait orientation.
Rotate the display 90 degrees counterclockwise. The “ ” logo should be on the right side when facing the display.
NOTE: The working hour in portrait mode is 24 hours per day.
90° 90°
2.5.1. How to remove the logo plate
1. Prepare a piece of paper with a cutting area of logo as a
protector to prevent the front bezel from scratching.
2. Use a knife and carefully remove the logo sticker with the
paper placing beneath.
3. Tear o the logo sticker.
1
2
3
NOTE: We recommend you contact a professional technician when installing the display on a wall. We are not responsible for
any damage to the product if the installation is not performed by a professional technician.
