Philips AX3217 - Electrical Parts List - Combi Board; Miscellaneous Electrical Parts; Capacitors List

6 - 1
ELECTRICAL PARTSLIST - COMBI BOARD
- MISCELLANEOUS - - CAPACITORS -
1100 4822 267 11027 CONNECTOR 16P 2314 4822 124 12095 100µF 20% 16V
1300
!
2422 086 10946 FUSE 630mA 65V 2315 3198 017 42230 22nF Y5V 50V
1301 2422 026 05086 CONNECTOR 2316 4822 126 14241 330pF NP0 50V
1302 2422 025 12272 CONNECTOR 6P 2317 3198 017 41050 1µF Y5V 10V
1401 4822 277 21705 SWITCH 2318 4822 124 42383 220µF 20% 4V
1402 4822 265 11248 CONNECTOR 24P 2319 4822 126 13193 4,7nF 10% X7R 63V
1403 2422 129 16818 PUSH SWITCH 2320 3198 017 41050 1µF Y5V 10V
1500 2422 026 05204 SOCKET PHONE H 1P 2321 4822 124 12245 220µF 20% 10V PM20 A
2322 4822 124 80349 47µF 20% 6,3V
- CAPACITORS - 2323 3198 017 41050 1µF Y5V 10V
2100 4822 124 12108 100µF 20% 4V 2324 3198 017 41050 1µF Y5V 10V
2102 3198 030 74780 4,7µF 20% 35V 2325 2238 586 59812 100nF +80-20% Y5V 50V
2106 4822 124 81058 47µF 20% 4V 2326 3198 017 42230 22nF Y5V 50V
2107 4822 126 14494 22nF 10% X7R 25V 2327 3198 030 74780 20% 35V 4,7µF
2108 4822 126 14494 22nF 10% X7R 25V 2328 4822 126 14241 330pF NP0 50V
2109 4822 126 13879 220nF +80-20% 16V 2329 4822 124 12108 100µF 20% 4V
2110 2238 586 59812 100nF +80-20% Y5V 50V 2330 5322 126 11583 10nF 10% X7R 50V
2111 3198 017 31530 15nF X7R 50V 2331 5322 126 11583 10nF 10% X7R 50V
2112 4822 126 13193 4,7nF 10% X7R 63V 2332 4822 126 14238 2,2nF X7R 50V
2113 3198 016 38210 820pF NP0 25V 2333 4822 126 13193 4,7nF 10% X7R 63V
2114 2020 552 94427 100pF 5% NP0 50V 2336 2238 586 59812 100nF +80-20% Y5V 50V
2115 4822 126 14238 2,2nF X7R 50V 2337 4822 124 23237 22µF 6,3V
2116 5322 126 11583 10nF 10% X7R 50V 2338 4822 124 23237 22µF 6,3V
2117 5322 126 11583 10nF 10% X7R 50V 2339 2238 586 59812 100nF +80-20% Y5V 50V
2118 2238 586 59812 100nF +80-20% Y5V 50V 2341
2238 586 59812
100nF +80-20% Y5V 50V
2119 4822 124 80349 47µF 20% 6,3V 2403 2238 586 59812 100nF +80-20% Y5V 50V
2121 2020 552 93645 39pF 5% NP0 50V 2404 2238 586 59812 100nF +80-20% Y5V 50V
2122 4822 126 14226 82pF 5% NP0 50V 2405 2238 586 59812 100nF +80-20% Y5V 50V
2200 3198 017 41050 1µF Y5V 10V 2406 2238 586 59812 100nF +80-20% Y5V 50V
2201 4822 122 33752 15pF 5% NP0 50V 2407 2238 586 59812 100nF +80-20% Y5V 50V
2202 4822 122 33752 15pF 5% NP0 50V 2501 4822 124 42383 220µF 20% 4V
2203 2238 586 59812 100nF +80-20% Y5V 50V 2502 4822 126 14491 2,2µF 10V
2204 2238 586 59812 100nF +80-20% Y5V 50V 2503 2222 867 15339 33pF 5% NP0 50V
2205 5322 126 11578 1nF 10% X7R 50V 2511 3198 030 74780 4,7µF 20% 35V
2206 4822 124 81058 47µF 20% 4V 2515 4822 126 14238 2,2nF X7R 50V
2207 2238 586 59812 100nF +80-20% Y5V 50V 2516 4822 126 14247 1,5nF X7R 50V
2208 4822 126 13879 220nF +80-20% 16V 2520 2238 586 59812 100nF +80-20% Y5V 50V
2209 5322 126 11583 10nF 10% X7R 50V 2522 4822 126 13883 220pF 5% 50V
2210 3198 017 44740 470nF Y5V 10V 2523 2238 586 59812 100nF +80-20% Y5V 50V
2211 4822 126 14494 22nF 10% X7R 25V 2524 4822 126 13883 220pF 5% 50V
2212 2238 586 59812 100nF +80-20% Y5V 50V 2525 4822 124 23002 10µF 16V
2213 4822 126 14494 22nF 10% X7R 25V 2526 3198 017 41050 1µF Y5V 10V
2214 2238 586 59812 100nF +80-20% Y5V 50V 2527 3198 030 74780 4,7µF 20% 35V
2215 4822 124 12108 100µF 20% 4V 2528 4822 126 14238 2,2nF X7R 50V
2216 3198 016 31020 1nF NP0 25V 2529 4822 126 14247 1,5nF X7R 50V
2217 2238 586 59812 100nF +80-20% Y5V 50V 2530 4822 126 14506 270pF 5% 50V NP0
2218 2238 586 59812 100nF +80-20% Y5V 50V 2532 4822 124 42383 220µF 20% 4V
2219 2238 586 59812 100nF +80-20% Y5V 50V 2533 4822 126 14491 2,2µF 10V
2305 3198 017 41050 1µF Y5V 10V 2534 2222 867 15339 33pF 5% NP0 50V
2313 2238 586 59812 100nF +80-20% Y5V 50V 2535 3198 017 41050 1µF Y5V 10V
