Philips AZ 1538 - Exploded View Diagram - Cabinet; Mechanical Parts List - Cabinet

12 - 1 12 - 1
@
@
(4x)
(4x)
2
2
4
#
(2x)
2
(2x)
(12x)
2
(4x)
(4x)
4
(4x)
6
(10x)
6
(2x)
6
(4x)
6
(1x)
6
8
(3x)
(3x)
6
9
(3x)
(4x)
!
(4x)
!
(1x)
(2x)
408
411
419
421
422
423
424
413
412
413
414
416
417
426
427
429
428
418
409
401
402
404
406
407
403
(2x)
14
SCREW LIST :
T3 x 6
T2 x 8
T2 x 10
T2.5 x 10
T3 x 8
T3 x 10
T3 x 12
T3 x 16
T3 x 20
T3 x 32
C P/W 2.5 x 10
T P/W 3 x 10
T P/W 3 x 12
1
2
3
4
5
6
7
8
9
0
!
@
#
T P/W 3 x 16
401 3140 114 42810 KNOB-VOKUME
402 3140 114 42920 KNOB-DBB/BAND
403 3140 117 63020 FRONT PANEL ASS’Y
404 3140 114 42820 CD BUTTON-PLAY/STOP
406 3140 114 42840 BUTTON-SEARCH
407 3140 114 42900 TUNER KEYSET
408 3140 117 63000 BOTTOM CABINET ASS’Y
409 3140 114 42850 MODE-LEVER
411 3140 114 42860 SLIDE-BASE
412
4822 529 10387 DAMPER - RUBBER (40 DEG)
414
413
3103 309 05410 CD MCD2-SC ASSY
416 4822 529 10386 DAMPER - RUBBER (30 DEG)
417 4822 529 10322 DAMPER ASSY
3140 111 01250 SPRING-CD DOOR
418
3140 117 63010 TOP CABINET ASS’Y
419
3140 114 42790 DOOR-CD
421
3140 114 42950 HANDLE
422
3140 118 71810 TELESCOPIC AERIAL
423
3140 114 41230 BATTERY DOOR
424
3140 114 41320 BATTERY COMPARTMENT
426
3140 111 00790 SPRING-PLUS/MINUS
427
3140 111 00780 SPRING-COMPRESSION (-)
428
429
3140 111 21320 CONTACT PLATE
Note:
Only these parts mentioned in the list are
normal service parts.

MECHANICAL PARTSLIST - CABINET
3103 308 66430 PBAS MP3CD2002 TXT
EXPLODED VIEW DIAGRAM - CABINET
