Philips AZ 2048 - Page 28

13 - 2
ELECTRICAL PARTSLIST - COMBI BOARD
- MISCELLANEOUS - - CAPACITORS -
1002 3103 308 66770 PBAS 8 MP3CD2002 2101 4822 126 11785 47pF 5% NP0 50V
1004 2422 264 00448 LOUDSPEAKER 4R 6W 2103 5322 126 11578 1nF 10% X7R 50V
1005 2422 264 00448 LOUDSPEAKER 4R 6W 2104 2020 552 94427 100pF 5% NP0 50V
1006 2422 264 00456 TWEETER D25 2106 2020 800 00191 CTRM 3-11pF N450
1007 2422 264 00456 TWEETER D25 2107 4822 121 51319 1µF 10% 63V
1008
!
3140 118 33440 TRANSFORMER 230V (-/00) 2110 2020 552 94427 100pF 5% NP0 50V
1008
!
3140 118 33451 TANSGORMER 110V (-/01) 2111 2222 867 15339 33 pF 5% NP0 50V
1009
!
2422 030 00333 AC SOCKET 2P 2120 4822 122 33761 22pF 5% NP0 50V ( -/00)
1010
!
2422 127 00453 VOLTAGE SELECTOR (-/01) 2120 3198 016 31890 18pF NP0 50V ( -/01)
1106 3140 114 50050 ANTENNA BAR 80MM ( -/00) 2122 5322 126 11579 3,3nF 10% X7R 63V
1106 2422 549 44211 FERRITE 5X13X55 ( -/01) 2123 2238 861 18391 390pF 1% NP0 50V
1252
!
2422 086 10783 FUSE RAD LT2A250V 2124 3198 017 32230 22nF X7R 25V ( -/01)
1300 2422 026 05076 CON BM PHONE H1P F3,5 2125 2238 861 18561 560pF 1% NP0 50V
1400 4822 265 11208 FCC CONNECTOR H 10P 2126 4822 126 14241 330pF NP0 50V
1403 4822 276 12889 MICRO SWITCH (CD DOOR) 2127 4822 126 13879 220nF +80-20% 16V
1405 3140 110 51460 LCD PANEL 2128 4822 124 40248 10µF 20% 63V
1700 4822 265 11208 FCC CONNECTOR H 10P 2129 4822 124 41584 100µF 20% 10V
1701 2422 128 02922 SWITCH TACT 1P 2130 3198 017 44740 470nF Y5V 10V
1702 2422 129 16349 ROT ENCODER 24P 2131 3198 017 44740 470nF Y5V 10V
1703 2422 128 02922 SWITCH TACT 1P 2132 3198 017 44740 470nF Y5V 10V
1704 2422 128 02922 SWITCH TACT 1P 2133 4822 124 21913 1µF 20% 63V
1705 2422 128 02922 SWITCH TACT 1P 2134 3198 017 31530 15nF X7R 50V
1706 2422 128 02922 SWITCH TACT 1P 2135 3198 017 31530 15nF X7R 50V
1707 2422 128 02922 SWITCH TACT 1P 2136 4822 126 13879 220nF +80-20% 16V
1708 2422 128 02922 SWITCH TACT 1P 2137 4822 126 13879 220nF +80-20% 16V
1709 2422 128 02922 SWITCH TACT 1P 2138 4822 124 22652 2,2µF 20% 50V
1710 2422 128 02922 SWITCH TACT 1P 2139 4822 122 33752 15pF 5% NP0 50V
1711 2422 128 02922 SWITCH TACT 1P 2140 4822 126 14226 82pF 5% NP0 50V
1712 2422 128 02922 SWITCH TACT 1P 2141 2238 586 59812 100nF +80-20% Y5V 50V
1713 2422 128 02922 SWITCH TACT 1P 2144 3198 017 44740 470nF Y5V 10V
1714 2422 128 02922 SWITCH TACT 1P 2145 4822 126 13883 220pF 5% 50V
1715 2422 128 02922 SWITCH TACT 1P 2146 4822 122 33575 220pF 5% NP0 63V
1716 2422 128 02922 SWITCH TACT 1P 2147 4822 126 13883 220pF 5% 50V
1717 2422 128 02922 SWITCH TACT 1P 2148 4822 126 14238 2,2nF X7R 50V
1718 2422 128 02922 SWITCH TACT 1P 2150 4822 126 14585 100nF 10% X7R 50V
1719 2422 128 02922 SWITCH TACT 1P 2152 4822 126 14549 33nF 16V X7R
1720 4822 265 11183 FCC CONNECTOR H 4P 2153 4822 122 33752 15pF 5% NP0 50V
1721 4822 267 10733 FCC CONNECTOR V 4P 2155 2020 800 00191 CTRM 3-11pF N450
1800 4822 267 11028 FCC CONNECTOR H 16P 2159 2222 867 15339 33pF 5% NP0 50V
1810 2422 540 98519 RES CER 8MHZ467 2163 2238 586 59812 100nF +80-20% Y5V 50V
8401 3139 111 01650 FFC FOIL 10P/120/10P 2164 3198 017 44740 470nF Y5V 10V
8411 3140 110 22200 HEAT SEAL 32P40MM 2165 2238 586 59812 100nF +80-20% Y5V 50V
8412 3139 110 35250 FFC FOIL 04P/120/04P 2166 5322 126 11578 1nF 10% X7R 50V
8801 3140 110 22270 FFC FOIL 19P/50/19P 2167 4822 126 11663 12pF 1%
8802 3103 308 93040 FFC FOIL 6P 2186 4822 124 40196 220µF 20% 16V
2187 5322 126 11583 10nF 10% X7R 50V
2188 5322 126 11583 10nF 10% X7R 50V
2189 4822 126 13879 220nF +80-20% 16V
2190 4822 124 81151 22µF 50V
2191 4822 124 81151 22µF 50V
