Philips AZ 2048 - Page 30

13 - 4
ELECTRICAL PARTSLIST - COMBI BOARD
- CAPACITORS - - CAPACITORS -
2533 2238 586 59812 100nF +80-20% Y5V 50V 2848 2020 552 94427 100pF 5% NP0 50V
2534 2238 586 59812 100nF +80-20% Y5V 50V 2849 4822 126 13883 220pF 5% 50V
2535 2238 586 59812 100nF +80-20% Y5V 50V 2850 4822 126 13883 220pF 5% 50V
2536 2238 586 59812 100nF +80-20% Y5V 50V 2851 4822 124 11947 10µF 20% 16V
2550 2238 586 59812 100nF +80-20% Y5V 50V 2853 5322 126 11583 10nF 10% X7R 50V
2551 4822 124 41407 0,47µF 20% 63V 2854 4822 124 23052 100µF 20% 16V
2552 4822 124 41407 0,47µF 20% 63V 2855 4822 124 11912 220µF 20% 6,3V
2553 3198 016 31020 1nF NP0 25V 2860 4822 126 14508 180pF 5% 50V NP0
2554 3198 016 31020 1nF NP0 25V 2861 4822 126 14241 330pF NP0 50V
2555 4822 124 41407 0,47µF 20% 63V 2862 3198 017 34730 47nF X7R 16V
2556 4822 124 41407 0,47µF 20% 63V 2863 4822 122 33753 150pF 5% NP0 50V
2557 3198 016 31020 1nF NP0 25V 2864 4822 122 33753 150pF 5% NP0 50V
2558 3198 016 31020 1nF NP0 25V 2865 4822 122 33753 150pF 5% NP0 50V
2700 5322 126 11583 10nF 10% X7R 50V 2866 4822 122 33753 150pF 5% NP0 50V
2701 5322 126 11583 10nF 10% X7R 50V 2869 3198 017 34730 47nF X7R 16V
2702 4822 124 80231 47µF 20% 16V 2870 4822 126 13883 220pF 5% 50V
2703 3198 016 31020 1nF NP0 25V 2871 4822 126 13883 220pF 5% 50V
2704 5322 126 11583 10nF 10% X7R 50V 2872 4822 126 13883 220pF 5% 50V
2812 4822 124 40248 10µF 20% 63V 2873 4822 126 13883 220pF 5% 50V
2813 5322 126 11582 6,8nF 10% X7R 63V 2874 4822 126 13883 220pF 5% 50V
2814 5322 126 11579 3,3nF 10% X7R 63V 2875 4822 126 13883 220pF 5% 50V
2815 4822 122 33753 150pF 5% NP0 50V 2876 4822 124 40196 220µF 20% 16V
2816 4822 126 14494 22nF 10% X7R 25V 2877 4822 124 40433 47µF 20% 25V
2817 4822 124 40769 4,7µF 20% 100V 2878 2238 586 59812 100nF +80-20% Y5V 50V
2818 3198 017 34730 47nF X7R 16V 2879 5322 126 11578 1nF 10% X7R 50V
2821 2238 586 59812 100nF +80-20% Y5V 50V 2880 2222 867 15339 33pF 5% NP0 50V
2822 4822 126 13344 1,5nF 5% 63V 2881 4822 126 14249 560pF 10% X7R 50V
2823 4822 124 42383 220µF 20% 4V 2882 4822 126 14226 82pF 5% NP0 50V
2825 4822 126 13344 1,5nF 5% 63V 2883 3198 017 44740 470nF Y5V 10V
2826 3198 017 34730 47nF X7R 16V 2884 3198 017 44740 470nF Y5V 10V
2827 5322 126 11578 1nF 10% X7R 50V
2828 4822 126 11669 27pF 1%
2829 3198 017 34730 47nF X7R 16V
2830 4822 124 81286 47µF 20% 16V
2831 4822 124 81286 47µF 20% 16V - RESISTORS -
2832 4822 126 14506 270pF 5% 50V NP0 3101 4822 051 30333 33K 5% 0,062W
2833 4822 126 14238 2,2nF X7R 50V 3102 4822 117 13632 100K 1% 0,62W
2834 4822 126 14506 270pF 5% 50V NP0 3103 4822 117 12902 8,2K 1% 0,063W
2835 4822 126 14247 1,5nF X7R 50V 3104 4822 117 13577 330R1% 1,25W
2836 4822 124 40433 47µF 20% 25V 3105 4822 051 30221 220R 5% 0,062W
2837 3198 017 34730 47nF X7R 16V 3101 4822 051 30333 33K 5% 0,062W
2838 4822 126 13879 220nF +80-20% 16V 3102 4822 117 13632 100K 1% 0,62W
2839 2238 586 59812 100nF +80-20% Y5V 50V 3103 4822 117 12902 100K 1% 0,63W
2840 4822 124 81286 47µF 20% 16V 3104 4822 117 13577 100K 1% 0,64W
2841 4822 126 13879 220nF +80-20% 16V 3105 4822 051 30221 100K 1% 0,65W
2843 2020 552 94427 100pF 5% NP0 50V 3106 4822 117 12139 22R 5% 0,062W
2844 4822 126 13883 220pF 5% 50V 3107 4822 051 30475 4,7M 5% 0,062W
2845 4822 126 13883 220pF 5% 50V 3108 4822 051 30222 2,2K 5% 0,062W
2846 4822 124 21732 10µF 20% 25V 3109 4822 051 30222 2,2K 5% 0,062W
2847 4822 126 13879 220nF +80-20% 16V 3123 4822 051 30472 4,7K 5% 0,062W
