Philips AZ 2048 - Page 34

13 - 8
ELECTRICAL PARTSLIST - COMBI BOARD
- RESISTORS - - RESISTORS -
3905 4822 051 30471 470R 5% 0,062W 4523 4822 051 30008 0R JUMPER
3906 4822 051 30471 470R 5% 0,062W 4552 4822 051 20008 0R JUMPER 0805
3907 4822 051 30391 390R 5% 0,062W 4801 4822 051 20008 0R JUMPER 0805
3908 4822 051 30222 2,2K 5% 0,062W 4802 4822 051 20008 0R JUMPER 0805
3909 4822 117 13632 100K 1% 0,62W 4803 4822 051 20008 0R JUMPER 0805
3910 4822 051 30471 470R 5% 0,062W 4805 4822 051 20008 0R JUMPER 0805
3916 4822 051 30471 470R 5% 0,062W 4808 4822 051 20008 0R JUMPER 0805
3917 4822 117 13608 4,7R 5% 0,0016W 4809 4822 051 20008 0R JUMPER 0805
4104 3198 021 90030 JUMPER 0R05 ( -/01) 4811 4822 051 20008 0R JUMPER 0805
4105 4822 051 30008 0R JUMPER 4817 4822 051 30008 0R JUMPER
4106 4822 051 30008 0R JUMPER 4818 4822 051 20008 0R JUMPER 0805
4107 4822 051 30008 0R JUMPER 4824 4822 051 20008 0R JUMPER 0805
4108 4822 051 30008 0R JUMPER 4827 4822 051 20008 0R JUMPER 0805
4109 4822 051 30008 0R JUMPER 4830 4822 051 20008 0R JUMPER 0805
4110 3198 021 90030 JUMPER 0R05 ( -/01) 4832 4822 051 20008 0R JUMPER 0805
4250 4822 051 20008 0R JUMPER 0805 4834 4822 051 20008 0R JUMPER 0805
4260 4822 051 30008 0R JUMPER 4836 4822 051 20008 0R JUMPER 0805
4400 4822 051 20008 0R JUMPER 0805 4840 4822 051 20008 0R JUMPER 0805
4402 4822 051 30008 0R JUMPER 4841 4822 051 20008 0R JUMPER 0805
4405 4822 051 30008 0R JUMPER 4842 4822 051 20008 0R JUMPER 0805
4407 4822 051 30008 0R JUMPER 4845 4822 051 30008 0R JUMPER
4408 4822 051 30008 0R JUMPER
4409 4822 051 30008 0R JUMPER
4410 4822 051 30008 0R JUMPER
4411 4822 051 30008 0R JUMPER - COILS & FILTERS -
4412 4822 051 30008 0R JUMPER 5001 2422 549 44607 IND FXD 100MHZ 2,7K
4413 4822 051 30008 0R JUMPER 5104 4822 157 11269 COIL MW ANT,( -/00)
4414 4822 051 30008 0R JUMPER 5104 2422 536 00364 IND FXD 190µH 5% ( -/01)
4415 4822 051 30008 0R JUMPER 5105 4822 157 11271 COIL LW ANT,
4416 4822 051 30008 0R JUMPER 5109 4822 242 70665 SFE10,7MS3-A
4417 4822 051 30008 0R JUMPER 5110 4822 242 70665 SFE10,7MS3-A
4418 4822 051 30008 0R JUMPER 5111 2422 549 44023 IND VAR 450KHZ
4420 4822 051 30008 0R JUMPER 5112 4822 157 70302 F7MCS-12216N
4422 4822 051 30008 0R JUMPER 5114 4822 157 70302 F7MCS-12216N
4430 4822 051 30008 0R JUMPER 5119 4822 157 11443 2,4µH 10,7M
4431 4822 051 30008 0R JUMPER 5121 4822 242 10261 T6252F00 75KHZ
4432 4822 051 30008 0R JUMPER 5122 2422 549 44108 IND VAR 796KHZ
4433 4822 051 30008 0R JUMPER 5123 2422 549 44108 IND VAR 796KHZ
4434 4822 051 30008 0R JUMPER 5130 4822 157 11843 MD7B-01F
4435 4822 051 20008 0R JUMPER 0805 5131 4822 157 11843 MD7B-01F
4436 4822 051 30008 0R JUMPER 5400 4822 157 11228 COIL 100µH LAN02 5%
4437 4822 051 30008 0R JUMPER 5401 2422 549 44393 IND FXD 100MHZ 2,7K
4438 4822 051 30008 0R JUMPER 5402 2422 540 98518 RES CER 8MHZ
4439 4822 051 30008 0R JUMPER 5404 2422 549 44393 IND FXD 100MHZ 2,7K
4440 4822 051 30008 0R JUMPER 5406 4822 157 11228 COIL 100µH LAN02 5%
4441 4822 051 30008 0R JUMPER 5408 4822 157 10686 CHOKE COIL 0,47µF
4442 4822 051 30008 0R JUMPER 5409 4822 157 10686 CHOKE COIL 0,47µF
4520 4822 051 30008 0R JUMPER 5410 4822 157 10686 CHOKE COIL 0,47µF
4521 4822 051 30008 0R JUMPER 5411 4822 157 10686 CHOKE COIL 0,47µF
4522 4822 051 30008 0R JUMPER 5412 4822 157 10686 CHOKE COIL 0,47µF
