Philips AZ1010 Service Manual

3-1
CS 49 110
DISMANTLING INSTRUCTIONS
Dismantling of the Cassette Door
• Open cassette door.
• Release left catch by pressing it inwards with a screwdriver
as shown in picture 1.
• Pull door on left side up as shown in picture 2.
• Right catch will now be released automatically.
picture 1
picture 2
Dismantling of the CD Door
• Open CD door.
• Release left catch by pressing it inwards with a screwdriver
as shown in picture 3.
• Pull door on left side up as shown in picture 4.
• Right catch will now be released automatically.
picture 3
picture 4

Philips AZ1010 Specifications

General

Brand	Philips
Model	AZ1010
Category	CD Player
Language	English
