Philips AZ1065 - Electrical Parts List - AF Board; AF Board Component Breakdown

13-3 13-3
PCS 107 133
ELECTRICAL PARTSLIST - AF BOARD
ELECTRICAL PARTSLIST - AF BOARD
- CAPACITORS - - RESISTORS -
2305 4822 124 80483 47µF 20% 6,3V 3326 4822 051 20561 560R 5% 0,1W
2306 4822 124 12052 220µF 20% 6,3V 3327 4822 051 20471 470R 5% 0,1W
2307 5322 122 31647 1nF 10% X7R 63V 3328 4822 117 11507 6K8 1% 0,1W
2308 4822 124 80791 470µF 16V 20% 3329 4822 116 83883 470R 5% 0,5W
2309 4822 126 14585 100nF 10% X7R 50V 3331 4822 116 52289 5K6 5% 0,5W
2337 5322 122 31863 330pF 5% 63V 3332 4822 116 52289 5K6 5% 0,5W
2338 5322 122 31863 330pF 5% 63V 3333 4822 116 83933 15K 1% 0,1W
2340 4822 124 11878 4700µF 16V 3334 4822 117 11383 12K 1% 0,1W
2341 4822 124 40196 220µF 20% 16V 3335 4822 117 11383 12K 1% 0,1W
2342 4822 124 40433 47µF 20% 25V 3501 4822 051 20822 8K2 5% 0,1W
2343 4822 124 41407 0,47µF 20% 63V 3502 4822 051 20822 8K2 5% 0,1W
2344 4822 124 41407 0,47µF 20% 63V 3505 4822 050 23303 33K 1% 0,6W
2345 4822 122 32535 680pF 10% X7R 63V 3506 4822 050 23303 33K 1% 0,6W
2346 4822 122 32535 680pF 10% X7R 63V 3507 4822 051 20822 8K2 5% 0,1W
2347 4822 124 40433 47µF 20% 25V 3508 4822 051 20822 8K2 5% 0,1W
2348 4822 124 40433 47µF 20% 25V 3509 4822 117 10833 10K 1% 0,1W
2349 4822 124 41407 0,47µF 20% 63V 3510 4822 117 10833 10K 1% 0,1W
2350 4822 124 41407 0,47µF 20% 63V 3541 4822 117 11139 1K5 1% 0,1W
2351 4822 124 80791 470µF 16V 20% 3542 4822 117 11139 1K5 1% 0,1W
2352 4822 124 80791 470µF 16V 20% 3543 4822 117 11449 2K2 5% 0,1W
2353 4822 124 40433 47µF 20% 25V 3544 4822 117 11449 2K2 5% 0,1W
2357 4822 126 13751 47nF 10% X7R 63V 3545 4822 117 10833 10K 1% 0,1W
2358 4822 126 13751 47nF 10% X7R 63V 3546 4822 117 10833 10K 1% 0,1W
2359 4822 124 40769 4,7µF 20% 100V 3561 4822 117 10965 18K 1% 0,1W
2360 4822 126 14585 100nF 10% X7R 50V 3562 4822 117 10965 18K 1% 0,1W
2361 4822 126 14585 100nF 10% X7R 50V 3563 4822 117 10833 10K 1% 0,1W
2363 4822 126 14585 100nF 10% X7R 50V 3564 4822 117 10833 10K 1% 0,1W
2531 4822 122 33177 10nF 20% X7R 50V 3565 4822 117 10837 100K 1% 0.1W
2532 4822 122 33177 10nF 20% X7R 50V 3566 4822 117 10837 100K 1% 0.1W
2533 4822 124 40746 0,22µF 20% 63V 9331 4822 051 20008 Jumper
2534 4822 124 40746 0,22µF 20% 63V 9332 4822 051 20008 Jumper
9333 4822 051 20008 Jumper
- RESISTORS - 9521 4822 051 20008 Jumper
9522 4822 051 20008 Jumper
3301 4822 117 11449 2K2 5% 0,1W
3302 4822 116 52256 2K2 5% 0,5W
- COILS -
3303 4822 051 20471 470R 5% 0,1W
3304 4822 051 20471 470R 5% 0,1W 5301 4822 157 11823 2,2µH 5%
3305 4822 117 10353 150R 1% 0,1W 5302 4822 157 62552 2,2µH
3306 4822 117 10353 150R 1% 0,1W
- DIODES -
3307 4822 051 20562 5K6 5% 0,1W
3311 4822 116 52206 120R 5% 0,5W 6308 3198 010 53380 Diode BZX79-B3V3
3312 4822 116 52206 120R 5% 0,5W 6311 4822 130 83757 Diode BAS216
3313 4822 117 11507 6K8 1% 0,1W 6316 4822 130 30621 Diode 1N4148
3314 4822 117 11507 6K8 1% 0,1W
3321 4822 050 24708 4R7 1% 0,6W
3322 4822 050 24708 4R7 1% 0,6W
3323 4822 051 20332 3K3 5% 0,1W
3325 4822 051 20391 390R 5% 0,1W
- IC & TRANSISTORS -
7301 4822 209 31544 IC TA8227P
7303 4822 130 41246 Trans BC327-25
7304 4822 130 41246 Trans BC327-25
7305 4822 130 60373 Trans BC856B
7306 5322 130 60159 Trans BC846B
7307 4822 130 40981 Trans BC337-25
7312 5322 130 60159 Trans BC846B
7313 4822 130 42615 Trans BC817-40
7314 4822 130 42615 Trans BC817-40
- MISCELLANEOUS -
1301 4822 277 11846 Slide Switch
1303 2422 026 05076 Headphone Socket
1314 2422 025 14518 Connector 9P
1501 4822 267 10731 Connector 6P
1502 4822 267 10731 Connector 6P
1504 4822 267 10733 Connector 4P
1506 4822 265 11515 Connector 8P
1510 4822 277 11786 Silde Switch
Note: Only these parts mentioned in the list are
normal service parts.
