CONTROLS
1 DBB (Dynamic Bass Boost) – to increase the bass level
2 VOLUME – to adjust the volume level
3 Cassette keys
PAUSE ; – to interrupt playback
STOP•OPEN 9/– to stop playback and open the cassette compartment
SEARCH 5 – to fast forward the tape
SEARCH 6 – to fast rewind the tape
PLAY 1 – to start playback
RECORD 0 – to start recording
4 CD buttons
PLAY•PAUSE 2; – to start or interrupt CD playback
STOP 9 – to stop playback
SEARCH ∞§– to skip or search a passage or a track
MODE – to select a different playback mode e.g. to SHUFFLE or REPEAT and to program track
numbers
5 CD display – to indicate CD functions
6 Cassette compartment
7 TUNING – to tune to radio stations
8 Tuning dial pointer
9 Band selector – to select the wave band (FM-MW)
0 OPEN – to open the CD door
! Source selector – POWER ON/OFF switch and to select the sound source: CD - RADIO - TAPE
@ p – 3.5 mm headphone socket
Note:
Connecting headphones will automatically disconnect the speakers
# Telescopic aerial – To improve FM reception
$ MAINS – for mains lead
% Battery door – to open the battery compartment
^ Voltage selector – (inside battery compartment)
Both the model and production numbers can be found on the bottom of the set.
BACK PANEL
TOP and FRONT PANEL
4
AZ 1110/01 page 4
English
AZ 1110/12 10/4/01 18:03 Page 4
