Philips AZ5155/01 - Electrical Parts List - Components; Miscellaneous Electrical Parts; Coils, Filters, Diodes, and Capacitors

12 - 1
ELECTRICAL PARTSLIST
- MISCELLANEOUS - - COILS & FILTERS -
1256 9965 000 20763 SLIDE SWITCH L20 9965 000 20549 10µH CHIP INDUCTOR
1302
!
9965 000 20760 FUSE 3,15A 250V L3 9965 000 20549 10µH CHIP INDUCTOR
1503 9965 000 20761 SLIDE SWITCH L301 9965 000 20756 10µH INDUCTOR
1504 9965 000 20762 SLIDE SWITCH L302 4822 157 71567 COIL 2,5T
1707 4822 277 11504 PUSH-SWITCH L303 9965 000 11817 FM COIL 3-1/2
T
9556 9965 000 20764 ROTARY SWITCH L306 9965 000 20756 10
µ
H INDUCTOR
CD SW 9965 000 20752 DOOR LATCH SWITCH L4 9965 000 20549 10
µ
H CHIP INDUCTOR
IR901 9965 000 20561 TSOP1838 IR RECEIVER L5 9965 000 20549 10µH CHIP INDUCTOR
J501 9965 000 20544 EARPHONE JACK L6 9965 000 20549 10µH CHIP INDUCTOR
J502 9965 000 20543 STEREO EARPHONE JACK L8 9965 000 20550 2,7µH SMD COIL
MIC501 9965 000 20765 3,5MM PHONE JACK L9 9965 000 20549 10µH CHIP INDUCTOR
MIC502 9965 000 20765 3,5MM PHONE JACK T301 9965 000 16786 MW OSC,COIL 843744
SW901 9965 000 20557 TACT SWITCH T302 9965 000 16787 IFT MW 843745
SW902 9965 000 20557 TACT SWITCH T303 4822 157 10689 FM DET COIL
SW903 9965 000 20557 TACT SWITCH T304 9965 000 16790 BAND PASS FILTER
SW904 9965 000 20557 TACT SWITCH X1 9965 000 20552 8,4672 MHZ CRYSTAL
SW906 9965 000 20557 TACT SWITCH X2 9965 000 14271 CRYSTAL 27MHZ
!
2422 070 98151 MAINSCORD EUR 1M5 BK B 9965 000 14465 AM COIL 100T
4822 277 30971 SWITCH
!
9965 000 08577 AC SOCKET - DIODES -
9965 000 10684 FERRITE BAR 6300 5322 130 34574 1N4004G
9965 000 20751 FLAT CABLE (FCC) 16P 6301 5322 130 34574 1N4004G
9965 000 20755 LCD DISPLAY 6302 5322 130 34574 1N4004G
9965 000 20768 MINIATURE PHONE JACK 6303 5322 130 34574 1N4004G
!
9965 000 20769 AC TRANSFORMER 6304 9965 000 20759 6,8V 1/2W ZENER DIODE
9965 000 20770 4" SPK,6 OHM 5-8W 6305 4822 130 30621 1N4148
6309 4822 130 30621 1N4148
6313 4822 130 30621 1N4148
6314 4822 130 30621 1N4148
- CAPACITORS & RESISTORS - 6316 4822 130 30621 1N4148
PVC301 9965 000 20563 PVC 20P-160P/20X2 6704 4822 130 30621 1N4148
RB1 9965 000 20553 100OHM X4 RESISTOR ARRAY D1 4822 130 30621 1N4148
RB2 9965 000 20553 100OHM X4 RESISTOR ARRAY D10 4822 130 30621 1N4148
RB6 9965 000 20554 10 KOHM X4 RESISTOR ARRAY D2 4822 130 30621 1N4148
VR501 9965 000 20766 VR 100KB D301 4822 130 30621 1N4148
VR502 9965 000 20766 VR 100KB D302 4822 130 30621 1N4148
D303 4822 130 30621 1N4148
D4 4822 130 30621 1N4148
D5 4822 130 30621 1N4148
- COILS & FILTERS - D601 4822 130 30621 1N4148
5701 4822 157 10371 COIL D602 4822 130 30621 1N4148
CF301 9965 000 16797 CERAMIC FILTER SFU465B D603 4822 130 30621 1N4148
CF302 9965 000 16789 LT10,7MS CER,FILTER D605 4822 130 30621 1N4148
L1 9965 000 20549 10µH CHIP INDUCTOR D606 5322 130 34574 1N4004G
L10 9965 000 20753 100µH 0,3A INDUCTOR D607 4822 130 30621 1N4148
L11 9965 000 20550 2,7µH SMD COIL D608 4822 130 30621 1N4148
L12 9965 000 20754 33µH CHOKE COIL D701 4822 130 30621 1N4148
L14 9965 000 20549 10µH CHIP INDUCTOR ZD1 5322 130 31504 BZX79-B3V3
L17 9965 000 20549 10µH CHIP INDUCTOR ZD301 9965 000 16799 ZENER DIODE 2,4V 1/2W
L19 9965 000 20549 10µH CHIP INDUCTOR ZD501 4822 130 34233 BZX79-B5V1
