11EN
5 Listen to FM
radio stations
Tune to FM radio stations
Note
For optimal reception, fully extend and adjust the
position of the FM antenna.
1 Switch the source selector to RADIO and
switch the band selector to FM.
2 Press / to tune to a radio station.
3 Repeat step 3 to tune to more stations.
To store the current radio station,
press PROG twice.
FM DAB
BAND
TAPE/OFF
AUDIO-IN/CD
RADIO
Program FM radio stations
automatically
Note
You can program a maximum of 20 preset radio
stations.
In FM tuner mode, press and hold PROG for 2
seconds to activate automatic programming.
» All available radio stations are stored
automatically, then the rst stored
radio station is broadcast.
» [FULL] is displayed when 20 preset
radio stations are stored.
Program FM radio stations
manually
Note
To overwrite a programmed radio station, store
another station in its place.
1 Tune to a radio station.
2 Press PROG to activate programming.
3 Press / to allocate a number to
this radio station, and then press PROG to
conrm.
» [STORED] and the frequency of this
radio station are displayed.
4 Repeat steps 1-3 to program more
stations.
Select a preset radio station
In tuner mode, press / to select a preset
station.
