23
7.Power Management
7. Power Management
If you have VESA DPM compliance display
card or software installed in your PC, the
monitor can automatically reduce its power
consumption when not in use. If an input
from a keyboard, mouse or other input
device is detected, the monitor will 'wake
up' automatically. The following table shows
the power consumption and signaling of this
automatic power saving feature:
Power Management Definition
VESA Mode Video H-sync V-sync
Power
Used
LED
Color
Active ON Yes Yes
21.1 W
(typ.)
141.6 W
(max.)
White
Sleep
(Standby
mode)
OFF No No
0.3 W
(typ.)
White
(blink)
Off mode
(AC switch)
OFF - - 0 W (typ.) OFF
The following setup is used to measure power
consumption on this monitor.
• Native resolution: 1920 x 1080
• Contrast: 50%
• Brightness: 90%
• Color temperature: 6500k with full white
pattern
Note
This data is subject to change without notice.

Philips B Line 243B9 Specifications

General

Haze rate	25 %
Pixel pitch	0.275 x 0.275 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	W-LED
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
NTSC coverage (typical)	90 %
Viewable size, vertical	296.5 mm
sRGB coverage (typical)	104 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.5 cm
Viewable size, horizontal	527 mm
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	30 - 85 kHz
Display brightness (typical)	250 cd/m²
Dynamic contrast ratio marketing name	SmartContrast
Component video sync	Separate sync, Sync-on-green (SOG)
RMS rated power	4 W
Number of speakers	2
Product color	Black
Market positioning	Business
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB Power Delivery up to	65 W
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR, RoHS, TCO, WEEE
Package type	Box
Package depth	162 mm
Package width	600 mm
Package height	476 mm
Package weight	8090 g
Cables included	AC
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	14.99 W
Power consumption (PowerSave)	12.8 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 30 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm

Weight and Dimensions

Depth (with stand)	216 mm
Width (with stand)	541 mm
Height (with stand)	522 mm
Weight (with stand)	5440 g
Depth (without stand)	63 mm
Height (without stand)	332 mm
Weight (without stand)	3830 g
