Philips BDL6520QL - Daisy-Chain Connectivity; Analog Video Daisy-Chaining; Network and RS232 Daisy-Chaining

BDL6520QL
12
Connectthe[DPOUT]connectorofDISPLAY1tothe[DPIN]connectorofDISPLAY2.
PC
[DP IN]
[DP]
[DP OUT] [DP IN]
DISPLAY 1 DISPLAY 2
Connectthe[DVIOUT]connectorofDISPLAY1tothe[DVIIN]connectorofDISPLAY2.
[DVI IN]
[HDMI]
[DVI OUT] [DVI IN]
DVD / VCR / VCD
DISPLAY 1 DISPLAY 2
3.4.3. Analog video connection
Connectthe[DVIOUT/VGAOUT]connectorofDISPLAY1tothe[VGAIN]connectorofDISPLAY2.
PC
DISPLAY 1 DISPLAY 2
[VGA IN]
[VGA]
[DVI/VGA OUT] [VGA IN]
Connect[Lancable]toDISPLAY1andconnectorthe[RS232COUT]connectorofDISPLAY1tothe[RS232IN]connecctortoDISPLAY2
PC
DISPLAY 1 DISPLAY 2
[RJ-45] [RS-232C OUT] [RS-232C IN]
[RJ-45]
