11
English
7 Reconnect the negative terminal of the car
battery.
Attach the front panel
1 Attach the trim plate.
2 Insert the left side of the panel in the
chassis until it is correctly engaged.
3 Press the right side of the panel until it is
locked into place.
4 Install the sleeve into the dashboard and

Note


5 Place the supplied rubber cushion over the
end of the mounting bolt.
6 Slide the unit into the dashboard until you
hear a click sound.
183 mm
53.5 mm
EN
