Philips DCM105 - Mechanical Partslist

9 - 2
MECHANICAL PARTSLIST
0001 996510029544 PCBA-MAIN (-/98)
0002 996510029553 PCBA-POWER/ECO (-/98)
0003 996510029537 PCBA-DIS/MCU (-/98)
0080 994000005085 CD MECHANISM DA11B3VZ (BALL)
110 994000005401 CD DOOR SPRING
201 996510029545 BOTTOM CABINET (-/98)
201 996510030959 BOTTOM CAB (-/05/12)
202 996510029611 FRONT PANEL
203 996510029548 BACK CABINET
204 996510029554 IPOD SUPPORT
205 996510029552 IPOD SUPPORT BKT
206 996510029547 SPRING COVER
207 996510029071 PANEL FIXER
208 996500039790 FM PIG TAIL HOUSING
209 996510029536 CD DOOR
210 994000004392 LASER COVER (FOR SANYO CD)
211 996510000864 CD GEAR BRACKET
212 996510000865 CD GEAR BLK
213 996510029546 DOCKING
214 996510029073 PANEL BUTTONS
215 996510029021 POWER BUTTONS
216 996500039338 IR LENS(WHITE)
217 996510029022 DISPLAY LENS
219 996510029026 TRIM RING
233 996510012604 CONNECTOR SLEEVE
J001
!
996510029287 AC SOCKET R-201A(B00) BLACK (-/98)
J002
994000004629
16P FFC CABLE 1MM L=120MM
J002
994000004629
16P FFC CABLE 1MM L
=
120MM
J003 996510019887 10P FFC.1mm L=160mm (-/98)
J003 996510031305 10P FFC.1MM 120MM (-/05/12)
J004 996510029543 26P FFC 1mm L=170mm (-/98)
J004 996510012652 26P FFC 1mm L=110mm (-/05/12)
S002 994000004376 SWITCH SL14-22AH-5AN (-/98)
S003 994000002354 CD DOOR SWITCH DLS-02-W-1
SPR01 996510029539 DOCK SPRING
T001
!
996510029535 TRANSFORMER VDE EI57 127/240V (-/98)
T001 ! 996510030962 TRANS. EI57 UP57-DCM105AT 230V (-/05/12)
ACCESSORIES
RC01 996510029541 REMORT CONTROL
0005 996510029549 SPK BOX (SINGLE L/R) (-/98)
SPK1 996510029549 SPK BOX (SINGLE L/R) (-/05/12)
J009
!
996510029404 AC CORD SET/10A 1.83M VDE APP (-/98)
J009 ! 996510031306 AC CORD BS PLUG VDE APP 2M (-/05)
J010 996510002103 CONN. CORD 3.5 ST/PLUGx2 500mm (-/98)
J010 996510002089 CONN. CORD 3.5 ST/PLUGx2 500mm (-/05/12)
Note: Only these parts mentioned in the list are
normal service parts.
218 996510014364 SCREW BUSHING (-/12)
J009 ! 996510000909 AC CORD VDE APP 2M (-/12)
